3 To 8 Layers Sintered Mesh Woven From 1 To 100 Micron

Place of Origin ANPING
Brand Name QIANPU

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Filtration, Sieving, Grading, Etc. Width 0.5-2.5m
Edge Treatment Cutting, Rolling, Etc. Mesh Count 2-635 Mesh
Thickness 0.02-2.03mm Surface Treatment Polished, Galvanized, Anodized, Etc.
Packing Carton, Wooden Case, Etc. Material Stainless Steel, Low Carbon Steel, Copper, Aluminum, Etc.
High Light

8 layers sintered mesh

,

100 micron woven sintered mesh

,

3 layers sintered mesh filter

Leave a Message
Product Description

Product Description:



Raw material: SS 304, SS 316L, bronze, nickel, Monel alloys, etc.
Common layers: 3-8layers
Filtrationrating: 1,2,5,10,15,20,30,40 or 75 micron
Diameter: 600-1200 mm
Mesh weaving type: dutch weave, square weave, plain weave, twill weave
Operating temperature: -200°Cto 600°C



Sintered woven wire mesh is fabricated by multiple woven wire meshes sintered together. With a higher strength than regular woven wire mesh, sintered woven wire mesh can reach a longer lifespan and ability to assume higher filtration flow rates.



By selecting different woven wires like 1,2,5,10,15,20,30mm, sintered woven wire mesh can be customized to achieve various filtration accuracy specifications. Moreover, we can design sintered woven wire mesh with your specific target thickness, permeability.



Features:

Easy to cut, bend and weld for various shapes
Superior filtration properties under demanding conditions
Ease of cleaning by both physical and chemical methods
Wide micron rating range from 1 to 100 micron
No additional skeleton support required with convenience installation

Technical Parameters:

Parameter Specification
Width 0.5-2.5m
Weave Type Plain Weave, Twill Weave, Dutch Weave, Etc.
Material Stainless Steel, Low Carbon Steel, Copper, Aluminum, Etc.
Length 10-100m
Shape Roll, Sheet, Plate, Etc.
Packing Carton, Wooden Case, Etc.
Mesh Count 2-635 Mesh
Features High Strength, Corrosion Resistance, Etc.
Wire Diameter 0.02-2.03mm
Edge Treatment Cutting, Rolling, Etc.
Temperature Range -200°C to 600°C
Material Stainless Steel, Stainless Steel Mesh, Sintered Wire Mesh


Applications:

Sintered woven wire mesh is usually used for various filtration applications such as the petrochemical, chemical industry, and water conditioning.


Customization:

Customized Service for Sintered Woven Wire Mesh

QIANPU provides customized service for sintered woven wire mesh with 3 to 8 layers and a diameter of 600mm to 1200mm.

Brand Name: QIANPU

Place of Origin: ANPING

Length: 10-100m

Weave Type: Plain Weave, Twill Weave, Dutch Weave, etc.

Edge Treatment: Cutting, Rolling, etc.

Application: Filtration, Sieving, Grading, etc.

Packing: Carton, Wooden Case, etc.



Support and Services:

Sintered Wire Mesh Technical Support and Service

Our team of experts provides quality technical support and service for Sintered Wire Mesh. We offer:

  • Remote and on-site troubleshooting and maintenance
  • Installation assistance and product customization
  • Product training and system integration support
  • Guidance on industry regulations and standards
  • Technical advice and product selection assistance


Packing and Shipping:

Sintered Wire Mesh Packaging and Shipping:

Sintered Wire Mesh is typically shipped in large rolls, in order to maintain the integrity of the mesh during shipping. The rolls are wrapped in protective packaging, such as plastic wrap or cardboard, to keep the mesh from being damaged during transit. The mesh is then placed in a sturdy cardboard box and sealed for safe transport.



FAQ:

Q1: What is Sintered Wire Mesh?
A1: Sintered Wire Mesh is a kind of wire mesh that is produced by sintering process. It is manufactured by QIANPU in ANPING, China.
Q2: What is the main material used to produce Sintered Wire Mesh?
A2: Sintered Wire Mesh is mainly made of stainless steel and other alloy materials.
Q3: What is the feature of Sintered Wire Mesh?
A3: Sintered Wire Mesh features good filtration performance, high temperature resistance, corrosion resistance and stability.
Q4: What is the application of Sintered Wire Mesh?
A4: Sintered Wire Mesh is widely used in air filtration, liquid and gas filtration, as well as chemical and medical industries.
Q5: What is the size of Sintered Wire Mesh?
A5: The size of Sintered Wire Mesh can be customized according to customer's requirements.
