Sus 304 Grade 20mesh Ss Woven Wire Mesh Plain Weave 0.35mm Diameter

  • Sus 304 Grade 20mesh Ss Woven Wire Mesh Plain Weave 0.35mm Diameter
  • Sus 304 Grade 20mesh Ss Woven Wire Mesh Plain Weave 0.35mm Diameter
  • Sus 304 Grade 20mesh Ss Woven Wire Mesh Plain Weave 0.35mm Diameter
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5 Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name SS Woven Wire Mesh Material SUS304
Surface Bright Silver Hole Shape Square Hole
Mesh Counts 20 Wire Diameter 0.35mm
Roll Width 1.3m Standard Length 30m
Properity Provides Excellent Corrosion And Oxidation Resistance Application Mining, Automotive, Etc
High Light

20mesh ss woven wire mesh

,

0.35mm diameter ss woven wire mesh

,

sus 304 plain weave wire mesh
Leave a Message
Product Description

SUS 304 Grade 20mesh Plain Weave 0.35mm Wire Diameter SS Woven Wire Mesh



Stainless Steel Woven Wire Mesh



T-304 stainless steel is the most widely available of all stainless steels in the wire mesh industry. Aside from the countless combinations of mesh opening sizes and diameter wire available both from stock and through manufacturing, T-304 SS exhibits many benefits and is largely considered the standard of the industry. T-304 SS has excellent corrosion resistance in a wide range of environments and is used in a wide range of applications.



Stainless steel :Stainless steel is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth.T304 is the most common, but other are used in specific applications to take advantage of each grade’s unique properties. The wire mesh made of stainless steel is extensively used in mining , chemical industry, food industry and pharmaceutical industry.


Our stainless steel wire mesh products are generally made of stainless steel Type 302,304,304L,316,316L,321 and 430 etc. We produce wire cloth in all kinds of forms. The weaving is determined according to our customers’ specific requirements, such as the material, the wire diameter, the size of the mesh , width and length.



Specifications:



Product Name SS304 Wire Mesh

Wire Dia.

(mm)

Meshes

(mesh/inch)

Width

(m)

Length

(m)
0.35 19 1.3 30m



Medium Standard Specifications:



Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
Inch MM Inch MM
12X12 0.023 0.584 0.06 1.52 51.8 42.2
12X12 0.02 0.508 0.063 1.6 57.2 31.6
14X14 0.023 0.584 0.048 1.22 45.2 49.8
14X14 0.02 0.508 0.051 1.3 51 37.2
16X16 0.018 0.457 0.0445 1.13 50.7 34.5
18X18 0.017 0.432 0.0386 0.98 48.3 34.8
20X20 0.02 0.508 0.03 0.76 36 55.2
20X20 0.016 0.406 0.034 0.86 46.2 34.4
24X24 0.014 0.356 0.0277 0.7 44.2 31.8
30X30 0.013 0.33 0.0203 0.52 37.1 34.8
30X30 0.012 0.305 0.0213 0.54 40.8 29.4
30X30 0.009 0.229 0.0243 0.62 53.1 16.1
35X35 0.011 0.279 0.0176 0.45 37.9 29
40X40 0.01 0.254 0.015 0.38 36 27.6
50X50 0.009 0.229 0.011 0.28 30.3 28.4
50X50 0.008 0.203 0.012 0.31 36 22.1
60X60 0.0075 0.191 0.0092 0.23 30.5 23.7
60X60 0.007 0.178 0.0097 0.25 33.9 20.4
70X70 0.0065 0.165 0.0078 0.2 29.8 20.8
80X80 0.0065 0.165 0.006 0.15 23 23.2
80X80 0.0055 0.14 0.007 0.18 31.4 16.9



Properties of Stainless Steel Wire Mesh

Type 304 is the basic stainless alloy, containing a minimum of 18% chromium and 8% nickel, provides excellent corrosion and oxidation resistance. It can be used at 800 degrees C for continuous service. It serves the needs of sorting and screening of liquids, powders, abrasives and other solids.

Type 316 is a special stainless alloy, which contains 18% chromium and 10% nickel, and the addition of molybdenum can be up to a maximum of 3%, so it offers a higher level of resistance to corrosion and heat than Type 304. The properties enable the mesh to withstand attack by salts, acids, seawater, and many industrial chemicals and solvents.



19mesh Plain Weave 0.35mm Wire Diameter SUS 304 Stainless Steel Wire Screen



Application:



General industrial use
Mining
Quarrying
Beer brewing
Water filtration
Particle separation
Automotive
Basket fabrication
Refinery & oil field
Aerospace
Food processing
Scientific & laboratory use



19mesh Plain Weave 0.35mm Wire Diameter SUS 304 Stainless Steel Wire Screen



Types of Woven Wire Mesh Cloth:



1.Market Grade Wire Mesh
The most commonly used industrial wire mesh, it is a kind of square or twill weave mesh.

2.Mill Grade Wire Mesh
It provides a greater percentage of open area than market grade, usually is square weave. Mainly used in the sizing and sifting applications.

3.Tensile Bolting Mesh
Tensile bolting wire mesh offers a highest percentage of open area, it is also suited in separation and filtering applications.

4.Dutch Weave Wire Cloth
Dutch weave filter cloth includes plain dutch and twill dutch weave wire cloth, can meet specific needs for gas and liquid filtration.
