Square Hole 80 To 635 Mesh SS Woven Wire Mesh , Fine Woven Wire Mesh

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5 Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product Name SS Woven Wire Mesh Material Stainless Steel
Surface Bright Silver Aperture Shape Square
Mesh Counts 90 To 635 Mesh Weaving Type Plain Weave Or Twill Weave
Corase Or Medium Or Fine Fine Mesh Roll Width Customized
Standard Length Customized Application Filtration
High Light

635 Mesh SS Woven Wire Mesh


80 Mesh SS Woven Wire Mesh


Square Hole fine woven wire mesh

Leave a Message
Product Description

Fine Mesh Stainless Steel Square Hole 80 to 635 Mesh SS Woven Wire Mesh


Fine Stainless Steel Woven Wire Cloth Introduction


We are specialized in producing and distributing stainless steel wire mesh, stainless steel wire cloth, stainless steel woven mesh, stainless steel filter mesh, stainless steel hardare cloth, stainless steel window screening,woven hardare cloth,stainless steel screen. Materials commonly with SUS201, SUS302, SUS304, 304L, SUS316, SUS316L, 310,310S, etc.


Plain Weave: also called tabby weave, linen weave or taffeta weave, is the most basic type of weaves. In plain weave, the warp and weft are aligned so they form a simple criss-cross pattern. Each weft thread crosses the warp threads by going over one, then under the next, and so on. The next weft thread goes under the warp threads that its neighbor went over, and vice versa.

Plain Dutch Weave.

Twill Weave: In a twill weave, each weft or filling yarn floats across the warp yarns in a progression of interlaces to the right or left, forming a distinct diagonal line. This diagonal line is also known as a wale. A float is the portion of a yarn that crosses over two or more yarns from the opposite direction.

Plain Dutch Weave: similar with plain weave, just the weft and warp wire have different wire diameter and different mesh size.

Twill Dutch Weave: similar with twill weave, just the weft and warp wire have different wire diameter and different mesh size.

Reverse Dutch Weave: difference from standard Dutch weave lies in the thicker warp wires and less weft wires.


Standard Specifications:

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
Inch MM Inch MM
90X90 0.005 0.127 0.0061 0.16 30.1 15.8
100X100 0.0045 0.114 0.0055 0.14 30.3 14.2
100X100 0.004 0.102 0.006 0.15 36 11
100X100 0.0035 0.089 0.0065 0.17 42.3 8.3
110X110 0.004 0.1016 0.0051 0.1295 30.7 12.4
120X120 0.0037 0.094 0.0064 0.1168 30.7 11.6
150X150 0.0026 0.066 0.0041 0.1041 37.4 7.1
160X160 0.0025 0.0635 0.0038 0.0965 36.4 5.94
180X180 0.0023 0.0584 0.0033 0.0838 34.7 6.7
200X200 0.0021 0.0533 0.0029 0.0737 33.6 6.2
250X250 0.0016 0.0406 0.0024 0.061 36 4.4
270X270 0.0016 0.0406 0.0021 0.0533 32.2 4.7
300X300 0.0051 0.0381 0.0018 0.0457 29.7 3.04
325X325 0.0014 0.0356 0.0017 0.0432 30 4.4
400X400 0.001 0.0254 0.0015 0.37 36 3.3
500X500 0.001 0.0254 0.001 0.0254 25 3.8
635X635 0.0008 0.0203 0.0008 0.0203 25 2.63

Other specifications according to your requirements.


Square Hole 80 To 635 Mesh SS Woven Wire Mesh , Fine Woven Wire Mesh 0

Materials: SS304 SS316

Weaving Type: Plain weave



High tension, much higher tension than common polyester mesh,and this property is very suitable.

Super precision: uniform wire diameter and aperture with extremely low difference.

Low elongation: very small elongation of wire mesh at high tension.

High flexibility: the wire mesh will not lose elasticity at extreme tension.

High corrosion resistance: the excellent corronsion resistance of stainless steel wire exceeds polyester fiber.

Non-electrostatic: to avoid affects of nonelectrostatic for printing and ensure the safety of priting.

Good heat melting resistance:special features of steel wire mesh suitable for heta-melting ink.

Good solvent resistance: to avoid the affects of any solvents to wire mesh.


This kind of stainless steel wire mesh are widely used in such fields as environmental protection, pharmaceutical industry, chemical industry, food industry, mechanical industry, smelting industry, coal mining, paper making, cement, construction industry, decoration, aeronautics and astronautics and so on.




Water-proof paper first then plastic film, in wooden case or pallets.


Square Hole 80 To 635 Mesh SS Woven Wire Mesh , Fine Woven Wire Mesh 1
