40 To 60 Mesh Wire Mesh Stainless Steel 316 0.15mm 0.17mm 0.19mm

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5 Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name SS Woven Wire Mesh Material Stainless Steel
Surface Bright Silver Hole Shape Square Hole
Mesh Counts 40, 50, 60 Mesh Per Inch Wire Diameter 0.19mm, 0.17mm, 0.15mm
Roll Width Customized Length 30m To 300m
Properity Low Internal Resistance Application For Battery Making.
High Light

60 Mesh Wire Mesh Stainless Steel 316

,

40 mesh Wire Mesh Stainless Steel 316

,

0.19mm 316 stainless steel mesh

Leave a Message
Product Description

Plain Weave 40 to 60Mesh Count Used as Mesh Battery SS Woven Wire Mesh



Stainless Steel Plain Weave for Battery Mesh Brief Introduction:



A lightweight woven wire mesh has been investigated as an battery current collector, fuel cells and electrolyzers. Using woven wire mesh as a current collector offers battery companies properties in battery that are not found in other products. As the mesh is made from two separate wires, it can withstand more flexure. It is ideal for electrode substrates, current collectors, flow field screens and gas diffusion electrodes.



It can be provided as discs or cut into mesh tapes. In addition, we designed special machines to produce the finish edge mesh. The finish edge will increase the mesh stability and provide a safety edge for handling. And It will also protect the battery separator.



We provide expertise in manufacturing stainless steel wire mesh in selecting the appropriate products for your battery requirements. As our wire mesh can be woven with different configurations and properties, we can tailor the product for your use. A multitude of meshes, weaves and wire diameters are available.



Battery Mesh Specifications:



Mesh Counts: 40mesh, 50mesh, 60mesh

Roll Width: 20mm to 500mm
Roll Length: 30m to 300m



Mesh Wire Diameter Aperture Open Area Rate
mm Inch mm Inch %
40 0.19 0.0074 0.445 0.0175 49.11
50 0.17 0.0066 0.338 0.0133 44.26
60 0.15 0.0059 0.273 0.0107 41.68


40 To 60 Mesh Wire Mesh Stainless Steel 316 0.15mm 0.17mm 0.19mm 0


Materials:



SS304, SS304L, SS316, SS316L.
Brass wire, copper wire, aluminum wire, nickel wire are available.


Weaving Type: Plain weave.


SS304, SS316 Plain Weave Wire Mesh as Mesh Battery, 40Mesh-60Mesh Count



Characteristics:


Safety edge, no obvious burrs;

Good stability, flexibility;

Acid and alkali resistance, high temperature resistance;

No fragment or rust happens in battery;

Good welding performance and easy fabricated;

Low internal resistance.


Applications:



Supercapacitor;
Rechargeable battery;

Gas diffusion electrodes;

Lithium manganese battery anode current collector;

Substrates for coating battery electrode material.
SS304, SS316 Plain Weave Wire Mesh as Mesh Battery, 40Mesh-60Mesh Count


Packing:

40 To 60 Mesh Wire Mesh Stainless Steel 316 0.15mm 0.17mm 0.19mm 3
