Galvanised Knitted Stainless Steel Mesh 0.1 To 0.55mm In Demister And Silencer Making

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50Rolls
Price Negotiable
Packaging Details Warpped with plastic film, then in wooden case or pallets.
Delivery Time 2 weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Alkali And Acid Resistance Product Name Knitted Wire Mesh
Standard Q/SG12-1-79 Q/YSZZ-88-91 Type Knitted
Material Galvanized Steel, Monel, Stainless Steel AISI201, 202, 301, 302, 304, 304L, 321, 316, 316 L, Inconel, Brass, Copper, Metal Alloys. Wire Diameter 0.10mm To 0.55mm
Typical Filtration Grades Standard; High Efficiency; Strong Penetration; Damping. Roll Width Up To 1600mm
Roll Length Up To 200m Applications Widely Used In Demister And Silencer Making
High Light

galvanised stainless steel knitted wire mesh

,

demister knitted stainless steel mesh

,

0.1mm knitted stainless steel mesh

Leave a Message
Product Description

Galvanised Steel Knitted Wire Mesh 0.1 To 0.55 Widely Used In Demister And Silencer Making

Introduction



Knitted Mesh is a special knit woven wire widely used in demister and silencer making. The final structure is of inter-connecting loops, similar to a long knit sock. We supply monofilament, multi-filament, co-knit and multi-strand knitted wire meshes processed from flat or round wire.



Typical applications: Knit wire mesh is major filter screen material, used in oil-gas separator, dust removing, mist removing, engine silencers, mechanical damping, also making of scourers.



Typical materials: Galvanized steel, Monel, Stainless steel AISI201, 202, 301, 302, 304, 304L, 321, 316, 316 L, Inconel, brass, copper, metal alloys.



Wire diameter sizes: 0.10 ~ 0.55mm



Typical Filtration Grades:
Standard;

High efficiency;
Strong penetration;
Damping.



Specifications:


Opening Sizes: from 1mm x 1mm to 10mm x 10mm.

Wire Diameters: from 0.1mm to 0.45mm.

Roll Width: 40mm, 80mm, 100mm, 150mm, 200mm, 300mm, 400, 500 mm, 600mm, etc.

Roll Length: 15m, 30m, 50m to 200m.



Item

Hole Number

Wire Diameter(mm)

Standard Knitted Wire Mesh

40-100

0.23,0.25,0.27,0.28

60-180

0.23,0.25,0.27,0.28

140-400

0.1*0.4

D--Wire Diameter; W1,W2, H--Hole Opening



Item

Hole Number

Wire Diameter(mm)

High Efficient Knitted Wire Mesh

70-100

0.23,0.25,0.28

80-100

0.1*0.3

90-100

0.1-0.3

D--Wire Diameter; W1,W2, H--Hole Opening



Item

Hole Number

Wire Diameter(mm)

High Penetrated Knitted Wire Mesh

20-160

0.15,0.23,0.28

30-150

0.15,0.23,0.28

70-400

0.15,0.23,0.28

D--Wire Diameter; W1,W2, H--Hole Opening



Common Specifications of Knitted Wire Mesh

Wire Diameter

(mm)

Opening Size

(mm)

Width

(mm)

Length

(m)

Number of Wires

(Nos.)

0.10

1.0-3.0

3-50

10-200

1-3

0.11

1.0-3.0

3-80

10-200

1-3

0.12

1.0-3.0

3-80

10-100

1-3

0.15

1.0-3.0

9-120

10-100

1-3

0.17

1.0-3.0

9-120

10-50

1-2

0.19

1.0-3.0

15-120

10-50

1-2

0.21

3.0-7.0

15-120

10-50

1-2

0.23

3.0-7.0

40-1000

10-50

1-2

0.25

3.0-7.0

40-1000

10-50

1-2

0.27

3.0-7.0

60-1000

10-50

1

0.28

3.0-7.0

60-1000

10-50

1

0.30

3.0-7.0

60-1000

10-50

1





Galvanised Knitted Stainless Steel Mesh 0.1 To 0.55mm In Demister And Silencer Making 0

Galvanised Knitted Stainless Steel Mesh 0.1 To 0.55mm In Demister And Silencer Making 1

Galvanised Knitted Stainless Steel Mesh 0.1 To 0.55mm In Demister And Silencer Making 2



KNITTED GALVANIZED WIRE MESH ROLLS

Material: Galvanised Steel
Width: 75mm
Length: 10m, 12m and 14m rolls



KNITTED MESH FABRIC, GALVANIZED BRIGHT
Knitted wire in rolls, 40 needles, 8 cm high, arround 6 kg/ roll, 4 rolls/ pvc bag
Made from: Electro Galvanized steel bright wire thickness 0.05 x 0.75 mm width, 20 gram zinc coated, Tensile strength 800-1000 N/m2



KNITTED MESH STRIP
Wire material: Galvanised mild steel wire
Diameter: 0.24 mm
Stitch number: 50
Strip width: 120mm

Features:



Galvanized mesh scrubbing pad features:
1) Not easy to change shape
2) Long live and not easy to change shape
3) Bright and shining, without smell
4) Well winding
5)Powerfull cleaning function
Zinc Plated Bright Scrubbing Wire:
Material: High quality low carbon steel wire or Q195
Wire gauge: 8#-28#(4.0mm-0.37mm)
Unit weight: 12g, 15g, 18g, 19g, 20g, 25g, 40g, 50g, 80g, 100g, etc,as per client's request.
Uses: For kitchen and housewares cleaning and scrubbing



Applications:



It can be used in the cable shields as a chassis grounding and electrostatic discharge;
Stainless steel knitted mesh can be installed onto the machine frames for EMI & RFI shielding industries, for elastomer cores and cable wrap;
It can be made into knitted mesh mist eliminator for gas and liquid filtration;
Stainless steel knitted mesh has outstanding filtering efficiency in various filtration device for air, liquid and gas filtration.







Packing:



Standard Type 0.1mm To 0.3mm Wire Long Lifespan Stainless Steel Knitted Wire Mesh 3



Our factory Photos:





Standard Type 0.1mm To 0.3mm Wire Long Lifespan Stainless Steel Knitted Wire Mesh 4
