SS304 Stainless Steel Knitted Wire Mesh 0.011" 42"
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Strong Corrosion Resistance | Product Name | Knitted Wire Mesh |
|---|---|---|---|
| Standard | Q/SG12-1-79 Q/YSZZ-88-91 | Type | Knitted |
| Material | SS304 | Wire Diameter | 0.011" |
| Weight | 50 LBs | Roll Width | 36", 42", Etc |
| Roll Length | As Required | Applications | For The Separation Of Liquid In The Gas. |
| Highlight | TENGLU 300 model SS304 Stainless Steel Knitted Wire Mesh,TENGLU 0.011" Stainless Steel Knitted Wire Mesh,42" ss mesh screen |
||
Product Description
304SS 0.011" Wire Weight 42" Width In Rolls Stainless Steel Knitted Wire Mesh
Knitted wire mesh rolls Introduction:
Knitted wire mesh rolls refer to the various materials are knitted into knitted wire mesh and then the wire meshes are rolled up for convenient usage and transport.
Knitted wire mesh rolls are available for various materials, the common materials are stainless steel wire, galvanized wire, copper wire, brass wire, nickel wire and monel wire.
The wire of knitted wire mesh rolls can be flat wire or round wire. The round wire knitted wire mesh rolls is the most commonly used type, which can be used almost all of the applications. The flat wire knitted wire mesh rolls have larger surface area than the round wire knitted wire mesh rolls. They can be used in the special applications according to customers' requirements.
The knitted wire mesh rolls can be made of mono-filament wires, which are widely used in the common applications for filtering and shielding. It can also be made of multi-filament wires, which has higher strength and can be used in the heavy duty applications.
Stainless Steel Knitted Wire Mesh Specifications:
|
Stainless Steel Knitted Wire Mesh |
||||
|
Types |
Model |
Wire Diameter |
Mesh Width |
Mesh Length |
|
standard type |
40-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
60-150 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
60-180 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
105-300 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
140-400 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
160-400 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
high efficient |
60-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
70-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
80-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
80-150 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
90-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
90-150 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
150-300 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
200-400 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
300-600 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
high penetrated |
20-100 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
20-160 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
30-150 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
70-400 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
170-600 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
180-700 |
0.10-0.30mm |
10-1600mm |
10-100m |
|
|
Notes: 1. 40-100 model: it has 40 openings in the mesh width of 100mm. 2. Common wire diameter includes 0.20mm, 0.23mm, 0.25mm, 0.28mm. 3. The mesh can be made into single strand, double strand, multi-strand etc. 4. The surface include flattened and crimped. 5. Material: stainless steel, caron steel, aluminum, brass, copper, nickel. |
||||
|
absorbed type |
20-40 |
0.10-0.20mm |
10-120mm |
10-100m |
|
30-40 |
0.10-0.20mm |
10-120mm |
10-100m |
|
|
30-50 |
0.10-0.20mm |
10-120mm |
10-100m |
|
|
30-60 |
0.10-0.20mm |
10-120mm |
10-100m |
|
|
30-80 |
0.10-0.20mm |
10-120mm |
10-100m |
|
|
50-120 |
0.10-0.20mm |
10-120mm |
10-100m |
|
|
Notes: 1. 50-120 model: it has 50 openings in the mesh width of 120mm. 2. Material: stainless steel, caron steel, aluminum, brass, copper, nickel. |
||||
Material:
Stainless steel: 201 202 302 304 304L 316 316L 321 430
Carbon steel : Q195 Q235 Q275
Brass: CuZn40 CuZn37 CuZn35 CuZn30 CuZn20 CuZn5
Copper: C10200 C11000
Aluminum: 1050 1060 1100 5052 5056 5083
Nickel: N2 N4 N6 Cr20Ni80 Monel400 Monel600
Plastic: PP PE
Features of knitted wire mesh rolls:
High strength.
Wide range of materials.
Single and multi-filament for choice.
Round and flat wire to be used in different applications.
Acid and alkali resistance.
Corrosion and rust resistance.
Excellent shielding performance.
Outstanding filtering capacity.
Easy to install and uninstall.
Durable and long service life.
Applications of knitted wire mesh rolls:
Knitted wire mesh rolls have various applications in our daily life and industries.
Knitted wire mesh rolls can be used as knitted cleaning mesh to clean the inside and outside of mechanical parts.
Knitted wire mesh rolls have excellent filtering performance, which can be used for gas, liquid separation and filtration.
Knitted wire mesh can be used as knitted wire mesh shielding in the cable shielding applications for excellent shielding capacity.
Packing:
Our factory Photos:
