Product Details
Features Remains Stable In High Temperature, Corrosion Product Name Incoloy 800 Wire Mesh
Material Incoloy 800 Woven Type Plain Weave, Twill Weave, Dutch Weave
Mesh Counts 2 To 400 Wire 0.025-1.80mm
Alloy Nickel, Iron And Chromium Application It Is Used Including Chemical, Nuclear, Petroleum, Food Processing Industries.
High Light

High Temperature Incoloy 800 Wire Mesh

,

Stable Structure Incoloy 800 Wire Mesh

,

Dutch Weave Incoloy 800 Wire Mesh
Leave a Message
Product Description

Incoloy 800 Wire Mesh Plain Weave Twill Weave Dutch Weave Stable Structure In High Temperature Corrosion



Incoloy800 Wire Mesh Introduction:



Incoloy 800 woven wire mesh is an alloy of nickel, iron and chromium that can still maintain a stable structure in prolonged high temperature. And it possesses excellent corrosion and high pressure. Incoloy wire mesh can service as the element of filter, demister, heating or carburizing equipment. What's more, it is used in other fields including chemical, nuclear, petroleum, food processing industries.



Material:



Pure Nickel Series: Nickel 200 (EN 2.4060), Nickel 201 (EN 2.4061), Nickel 270 (EN 2.4050)
Nickel Alloy Series: Cr20Ni80 (EN 2.4869)



Incoloy 800 Woven Wire Mesh Chemical Composition (%)
Cr Ni C ≤ Si ≤ Mn ≤ P ≤ S ≤ Fe
19.0–23.0 30.0–35.0 0.1 1 1.5 0.03 0.015 balance




Nickel 200 and 201 are considered as commercially pure. With 99.6% grade, the low carbon content of 201 prevents the metal alloy from becoming brittle when exposed to temperatures 600F and above. The Nickel 270 is considered as high purity grade metal alloy, produced through powder metallurgy.



Features:



Maintain a stable structure in high temperature and high pressure;
Excellent resistance to stress corrosion cracking, alkali corrosion;
Good welding performance and ductility.



Applications:



Service as filter, heating element, demister;
Used for the element of carburizing equipment, heat exchanger, furnace components;
Used in chemical, oil, nuclear, nitric acid cooler equipment, food processing industries.



Specifications:

Specifications of Nickel 200 Wire Mesh
Mesh Wire Diameter Opening
mm inch (mm)
2 mesh 1.8 0.071 10.9
3 mesh 1.6 0.063 6.866
4 mesh 1.2 0.047 5.15
5 mesh 0.91 0.036 4.17
6 mesh 0.711 0.028 3.522
8 mesh 0.61 0.024 2.565
10 mesh 0.508 0.02 2.032
12 mesh 0.457 0.018 1.66
14 mesh 0.417 0.016 1.397
16 mesh 0.345 0.014 1.243
18 mesh 0.315 0.012 1.096
20 mesh 0.315 0.0124 0.955
22 mesh 0.315 0.0124 0.84
24 mesh 0.315 0.0124 0.743
26 mesh 0.295 0.0116 0.682
28 mesh 0.295 0.0116 0.612
30 mesh 0.274 0.011 0.573
32 mesh 0.254 0.01 0.54
34 mesh 0.234 0.0092 0.513
36 mesh 0.234 0.0092 0.472
38 mesh 0.213 0.0084 0.455
40 mesh 0.193 0.0076 0.442
42 mesh 0.193 0.0076 0.412
44 mesh 0.173 0.0068 0.404
46 mesh 0.173 0.0068 0.379
48 mesh 0.173 0.0068 0.356
50 mesh 0.173 0.0068 0.335
60 mesh 0.173 0.0068 0.25
70 mesh 0.132 0.0052 0.231
80 mesh 0.122 0.0048 0.196
90 mesh 0.112 0.0044 0.17
100 mesh 0.012 0.004 0.152
120 mesh 0.081 0.0032 0.131
140 mesh 0.061 0.0024 0.12
150 mesh 0.061 0.0024 0.108
160 mesh 0.061 0.0024 0.098
180 mesh 0.051 0.002 0.09
200 mesh 0.051 0.002 0.076
220 mesh 0.051 0.002 0.065
250 mesh 0.041 0.0016 0.061
280 mesh 0.035 0.0014 0.056
300 mesh 0.031 0.0012 0.054
320 mesh 0.031 0.0012 0.046
330 mesh 0.031 0.0012 0.042
350 mesh 0.031 0.0012 0.039
360 mesh 0.025 0.00098 0.0385
400 mesh 0.025 0.00098 0.0385

Other specifications according to your request.



Incoloy 800 Wire Mesh Plain Weave Twill Weave Dutch Weave Stable Structure In High Temperature Corrosion 0



Packing:



Pure Nickel Plain Weave Wire Mesh, 80mesh to 200mesh With 0.04-0.15mm Wire
