PTFE Coated Metal Woven Wire Mesh

  • PTFE Coated Metal Woven Wire Mesh
  • PTFE Coated Metal Woven Wire Mesh
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Chemically Resistant And Self- Lubricating. Product Name PTFE Coated Wire Mesh
Material SS304/ SS316 Surface PTFE Coated
Mesh Counts 200 Per Inch Weaving Type Plain Dutch
Wire Diameter 0.0021" Color Green
STANDARD ASTM, AISI Application Commonly Used As Filter Element In Industrial Applications
High Light

PTFE Coated Metal Woven Wire Mesh

,

PTFE Coated SS316 Metal Woven Wire Mesh

,

PTFE Coated metal wire mesh
Leave a Message
Product Description

Green PTFE Coated Wire Mesh With Fantastic Hydrophobic Performance



PTFE COATED WIRE MESH INTRODUCTION:



PTFE coated wire mesh refers to woven wire mesh which is coated with fine Teflon resin. The wire mesh, with mesh size of 100 per inch, 200 per inch or 325 per inch, is woven from stainless steel wire diameter which is heavier than that used to weave bolting cloth. The (Teflon) coating serves to increase the hydrophobic properties of the filter by allowing the passage of fuel but inhibiting the passage of water in the coalescer-based system. Finished products are specific used for filter devices, especially for industrial cartridge filters in high-temperature and chemical-resistant applications.

Green color may be inconsistent from roll to roll or even within the roll. This variation does not affect performance.



Material:


Wire mesh: stainless steel 304/316L
Coating: Polytetrafluoroethylene (TEFLON) resin.



Specification



Wire diameter: 0.0014", 0.0021", 0.0045".
Mesh size: 100, 200, 325 per inch.
Temperature Range: -73 °C to 260 °C.
Color: green.
Standard: ASTM



mesh/inch Wire diameter Opening Opening Microns Open area Weight
inch mm mm % lb/sq. ft 　
200 0.0021 0.05334 0.07366 74 33.6 0.06



PTFE Coated Metal Woven Wire Mesh 0



Features



Excellent hydrophobic performance.
Wide range of working temperature.
Chemically resistant and self-lubricating.
High tear-strength and good flex-life.
Designed for efficient operation & cost saving.
Easily to clean during maintenance & service operations.



Application


PTFE coated wire mesh are commonly used as filter element in industrial applications.
Chemicals, resins and solvents.
Hydraulic oils.
Petroleum refining.
Power generation.
Pulp and paper industry.
Fuel lines.



Package:



packed in roll, wrapped with moister-proof paper, put into wooden cases, or according to your requirements.



PTFE Coated Metal Woven Wire Mesh 1
