Woven 1.8mm Nickel 200 Wire Mesh In Fiber Chemical Electrical Industry

  • Woven 1.8mm Nickel 200 Wire Mesh In Fiber Chemical Electrical Industry
  • Woven 1.8mm Nickel 200 Wire Mesh In Fiber Chemical Electrical Industry
  • Woven 1.8mm Nickel 200 Wire Mesh In Fiber Chemical Electrical Industry
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 2Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Excellent Mechanical Properties And Ductility Product Name Nickel 200 Wire Mesh
Material Nickel Wire Woven Type Plain Weave, Twill Weave, Dutch Weave
Mesh Counts 2 To 400 Wire 0.025-1.80mm
Thickness ≥ 0.08 Mm Application In Fiber Chemical Electrical Industry
High Light

Woven Nickel 200 Wire Mesh

,

1.8mm Nickel 200 Wire Mesh
Leave a Message
Product Description

Nickel 200 Wire Mesh With Excellent Mechanical Properties Used In Fiber Chemical Electrical Industry



Nickel Woven Wire Mesh Introduction:



Nickel 200 wire mesh has excellent mechanical properties and ductility with high purity nickel. It resists to high temperature and corrosion and has good electrical and thermal conductivity, magnetostrictive properties. Nickel wire mesh can be used for filter or element of heating, food processing and salt refining equipment. It also provides service in mining, marine, electrical, chemical industries.



Material:



Pure Nickel Series: Nickel 200 (EN 2.4060), Nickel 201 (EN 2.4061), Nickel 270 (EN 2.4050)
Nickel Alloy Series: Cr20Ni80 (EN 2.4869)



Table 1: Nickel 200 Wire Mesh Chemical Composition (%)
Ni Fe ≤ C ≤ Mn ≤ Si ≤ Cu ≤ S ≤
balance 0.4 0.15 0.35 0.35 0.25 0.01



Nickel 200 and 201 are considered as commercially pure. With 99.6% grade, the low carbon content of 201 prevents the metal alloy from becoming brittle when exposed to temperatures 600F and above. The Nickel 270 is considered as high purity grade metal alloy, produced through powder metallurgy.



Features:



Excellent acid, alkali, chemicals corrosion resistance;
Superior thermal and electrical conductivity, magnetostrictive properties;
Abrasion and high temperature resistance;
Good ductility and strength.



Applications:



Service as filter in chemical, mining, food, petroleum, machine industries;
Used for conductive or heating elements;
Play an important role in electrical, machine, salt refining, marine development, etc.



Specifications:

Specifications of Nickel 200 Wire Mesh
Mesh Wire Diameter Opening
mm inch (mm)
2 mesh 1.8 0.071 10.9
3 mesh 1.6 0.063 6.866
4 mesh 1.2 0.047 5.15
5 mesh 0.91 0.036 4.17
6 mesh 0.711 0.028 3.522
8 mesh 0.61 0.024 2.565
10 mesh 0.508 0.02 2.032
12 mesh 0.457 0.018 1.66
14 mesh 0.417 0.016 1.397
16 mesh 0.345 0.014 1.243
18 mesh 0.315 0.012 1.096
20 mesh 0.315 0.0124 0.955
22 mesh 0.315 0.0124 0.84
24 mesh 0.315 0.0124 0.743
26 mesh 0.295 0.0116 0.682
28 mesh 0.295 0.0116 0.612
30 mesh 0.274 0.011 0.573
32 mesh 0.254 0.01 0.54
34 mesh 0.234 0.0092 0.513
36 mesh 0.234 0.0092 0.472
38 mesh 0.213 0.0084 0.455
40 mesh 0.193 0.0076 0.442
42 mesh 0.193 0.0076 0.412
44 mesh 0.173 0.0068 0.404
46 mesh 0.173 0.0068 0.379
48 mesh 0.173 0.0068 0.356
50 mesh 0.173 0.0068 0.335
60 mesh 0.173 0.0068 0.25
70 mesh 0.132 0.0052 0.231
80 mesh 0.122 0.0048 0.196
90 mesh 0.112 0.0044 0.17
100 mesh 0.012 0.004 0.152
120 mesh 0.081 0.0032 0.131
140 mesh 0.061 0.0024 0.12
150 mesh 0.061 0.0024 0.108
160 mesh 0.061 0.0024 0.098
180 mesh 0.051 0.002 0.09
200 mesh 0.051 0.002 0.076
220 mesh 0.051 0.002 0.065
250 mesh 0.041 0.0016 0.061
280 mesh 0.035 0.0014 0.056
300 mesh 0.031 0.0012 0.054
320 mesh 0.031 0.0012 0.046
330 mesh 0.031 0.0012 0.042
350 mesh 0.031 0.0012 0.039
360 mesh 0.025 0.00098 0.0385
400 mesh 0.025 0.00098 0.0385

Other specifications according to your request.



Woven 1.8mm Nickel 200 Wire Mesh In Fiber Chemical Electrical Industry 0



Packing:



Pure Nickel Plain Weave Wire Mesh, 80mesh to 200mesh With 0.04-0.15mm Wire
