High Strength Monel K500 Wire Mesh Corrosion Resistance In Aerospace Chemical

  • High Strength Monel K500 Wire Mesh Corrosion Resistance In Aerospace Chemical
  • High Strength Monel K500 Wire Mesh Corrosion Resistance In Aerospace Chemical
  • High Strength Monel K500 Wire Mesh Corrosion Resistance In Aerospace Chemical
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 2Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Monel Woven Wire Mesh Material Monel K500
Standard ASTM Composed Primarily Of Copper And Nickel
Wire Diameter 0.05 To 1.80mm Hole Shapes Square
Mesh Counts 2 To 200 Per Inch Weave Type Plain Weave, Twill Weave, Dutch Weave.
Feature Has Higher Tensile And Yield Strength Applicatioin Aerospace, Chemical
High Light

Aerospace Monel K500 Wire Mesh

,

Chemical Monel K500 Wire Mesh

,

High Strength Monel K500 Wire Mesh
Leave a Message
Product Description

High Strength Monel K500 Wire Mesh Good Corrosion Resistance In Aerospace, Chemical



Monel k500 wire mesh introduction:



Monel K500 wire mesh possesses good corrosion resistance like the monel 400 wire mesh. Adding aluminum, titanium, it has higher tensile and yield strength.



Monel wire mesh can be made into filter disc or tube, heat exchanger, etc. And it play an important role in chemical, petroleum, aerospace, marine, paper making equipment.



Material:


Monel400, Monel401, Monel404, Monel R405, Moenl K500 and Inconel wire. Monel400 alloy wire is the most common material that corrosion resisting in the hydrofluoric acid, muriatic acid, phosphoric acid, organic acid and alkaline medium.



Monel K500 Wire Mesh Chemical Composition (%)
Ni ≥ Cu Al Ti Fe ≤ Mn ≤ S ≤ C ≤ Si ≤
63 27.0–33.0 2.30–3.15 0.35–0.85 2 1.5 0.01 0.25 0.5



Weave Pattern: plain weave, twill weave, dutch weave.


Features:



Superior corrosion resistance and acid-alkali resistance;
Resist to high temperature resistance, stress corrosion cracking;
High hardness, tensile and yield strength;
Durable and has a long service life.

Applicatioin:



Used for filter or heating element, pressure vessel;
Serve in boiler feed water heater, chemical, paper making devices, and in petroleum, aerospace, marine industries.

The most popular specification:


Monel Wire Mesh
Mesh Wire Dia. (mm) Aperture (mm)
2mesh 1.80 10.90
3mesh 1.60 6.866
4mesh 1.20 5.15
5mesh 0.91 4.17
6mesh 0.80 3.433
8mesh 0.60 2.575
10mesh 0.55 1.990
12mesh 0.50 1.616
14mesh 0.45 1.362
16mesh 0.40 1.188
18mesh 0.35 1.060
20mesh 0.30 0.970
26mesh 0.28 0.696
30mesh 0.25 0.596
40mesh 0.21 0.425
50mesh 0.19 0.318
60mesh 0.15 0.273
70mesh 0.14 0.223
80mesh 0.12 0.198
90mesh 0.11 0.172
100mesh 0.10 0.154
120mesh 0.08 0.132
140mesh 0.07 0.111
150mesh 0.065 0.104
160mesh 0.065 0.094
180mesh 0.053 0.088
200mesh 0.053 0.074

Other specifications according to your requirements.


Usage:


This mesh can be used make heat exchangerm,pressure vessels,value,pump,reaction kettles and oil pipes.




Packing:


Inside with a paper core, outside with a piece of waterproof, the in wooden case.
