Monel 400 Wire Mesh With Excellent Corrosion Resistanc Used In Refinery Desalination Salt Production

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 2Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Monel Woven Wire Mesh Material Monel 400
Standard ASTM Composed Primarily Of Copper And Nickel
Wire Diameter 0.05 To 1.80mm Hole Shapes Square
Mesh Counts 8 To 200 Per Inch Weave Type Plain, Twill
Feature Excellent Resistance To High Temperature Corrosion And Stress Corrosion Cracking Applicatioin Used For Element Of Heat Exchanger Equipment, Boiler Feed Water Heater, Chemical Processing Equipment
High Light

Refinery Desalination Monel Wire Mesh

,

Salt Production Monel Wire Mesh

,

Corrosion Resistanc Monel 400 Wire Mesh

Leave a Message
Product Description

Monel 400 Wire Mesh With Excellent Corrosion Resistanc Used In Refinery Desalination Salt Production



Monel 400 wire mesh introduction:



Monel 400 wire mesh is a kind of nickel-based alloy material, possessing excellent corrosion resistance. With good resistance to oxidation and reduction media, high temperature and seawater corrosion, it also has high strength, toughness and good welding performance.

Monel 400 wire cloth can be made into filter, heating element, demister. What's more, it also can meet your application needs in refinery, boiler feed water heaters, salt production, desalination, or chemical equipment, etc.


Monel 400 alloy contains minimum 63% nickel and 28% copper. It is essentially non-corrodible. It Is more resistant than copper to oxidation and is more resistant than nickel to reducing conditions. Monel was very popular in the past for food processing due to its excellent corrosion resistance and high strength. This 400 grade monel is highly resistant to the corrosive action of acids, alkalides and salt water. It has the same strength of mild steel.



Material:


Monel400, Monel401, Monel404, Monel R405, Moenl K500 and Inconel wire. Monel400 alloy wire is the most common material that corrosion resisting in the hydrofluoric acid, muriatic acid, phosphoric acid, organic acid and alkaline medium.



Monel-400 Chemical Composition(%)
C Mn Fe Cu Ni Si S
Max Max Max Min/Max Min Max Max
0.3 2 2.5 28.0-34.0 63 0.5 0.024



Weave Pattern: plain weave, twill weave, dutch weave.


Features:



Excellent resistance to high temperature corrosion and stress corrosion cracking;
Superior resistance to acid, alkali, fluoride, seawater corrosion;
High strength and good processing performance;
Good toughness and welding performance.

Applicatioin:



Made into filter, demister, heating element;
Used for element of heat exchanger equipment, boiler feed water heater, chemical processing equipment;
Play an important role in refinery, salt production, desalination.

The most popular specification:


Monel Wire Mesh
Mesh Wire Dia. (mm) Aperture (mm)
2mesh 1.80 10.90
3mesh 1.60 6.866
4mesh 1.20 5.15
5mesh 0.91 4.17
6mesh 0.80 3.433
8mesh 0.60 2.575
10mesh 0.55 1.990
12mesh 0.50 1.616
14mesh 0.45 1.362
16mesh 0.40 1.188
18mesh 0.35 1.060
20mesh 0.30 0.970
26mesh 0.28 0.696
30mesh 0.25 0.596
40mesh 0.21 0.425
50mesh 0.19 0.318
60mesh 0.15 0.273
70mesh 0.14 0.223
80mesh 0.12 0.198
90mesh 0.11 0.172
100mesh 0.10 0.154
120mesh 0.08 0.132
140mesh 0.07 0.111
150mesh 0.065 0.104
160mesh 0.065 0.094
180mesh 0.053 0.088
200mesh 0.053 0.074

Other specifications according to your requirements.

Monel 400 Wire Mesh With Excellent Corrosion Resistanc Used In Refinery Desalination Salt Production 0

There is a filter disc made of monel 400 wire cloth.


Usage:


This mesh can be used make heat exchangerm,pressure vessels,value,pump,reaction kettles and oil pipes.

Monel Wire Mesh, Monel400 Grade, 200mesh, 0.053mm, Wire 1.0m Wide.


Packing:


Inside with a paper core, outside with a piece of waterproof, the in wooden case.

Monel 400 Wire Mesh With Excellent Corrosion Resistanc Used In Refinery Desalination Salt Production 3
