Corrosion Resistance Hastelloy C 276 Wire Mesh In Hot Concentrated Sulfuric Acid Solution

  • Corrosion Resistance Hastelloy C 276 Wire Mesh In Hot Concentrated Sulfuric Acid Solution
  • Corrosion Resistance Hastelloy C 276 Wire Mesh In Hot Concentrated Sulfuric Acid Solution
  • Corrosion Resistance Hastelloy C 276 Wire Mesh In Hot Concentrated Sulfuric Acid Solution
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 2Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Has Excellent Corrosion Resistance To Pitting And Crevice Corrosion. Product Name Hastelloy Woven Wire Mesh
Material Hastelloy C-276 Standard ASTM
Hole Shapes Square Woven Type Plain Weave, Twill Weave
Mesh Counts 2 To 300 Roll Length 30m
Roll Width 0.5m - 3.0m Usages Widely Used In Petrochemical, Flue Gas Desulfurization, Pulp And Paper Production, Waste Treatment, Environmental Protection Industry, Etc.
Highlight

Corrosion Resistance hastelloy c 276 wire mesh

,

ISO hastelloy c 276 wire mesh

,

ASTM hastelloy c 276 wire mesh
Leave a Message
Product Description

Hastelloy C-276 Wire Mesh With Excellent Corrosion Resistance Used In Hot Concentrated Sulfuric Acid Solution



Hastelloy Woven Wire Mesh Introduction:



Hastelloy C-276 wire mesh is nickel-molybdenum-chromium alloy with the addition of tungsten, and has excellent corrosion resistance to pitting and crevice corrosion. It is also the rare materials that can be used in hot concentrated sulfuric acid solution.

With good performance, hastelloy C276 wire mesh can be made into gas-liquid filter, demister or be widely used in petrochemical, flue gas desulfurization, pulp and paper production, waste treatment, environmental protection industry, etc.



Materials:

Chemical Composition of Material
Type C Co Cr Cu Fe Mn Mo Ni P S Si Sn V W
H-B 0.12 2.5 1 - 6 1 26.0 - 30.0 Rem. 0.01 - 0.03 - 0.6 -
H-C22 0.015 2.5 14.5 - 20.0 - 2.0 - 6.0 0.5 12.8 - 14.5 Rem. - 0.02 0.08 - 0.35 -
H-C276 0.02 2.5 14.5 - 16.5 - 4.0 - 7.0 1 15.0 - 17.0 Rem. 0.03 0.03 0.08 - 0.35 3.0 - 4.5
H-X 0.08 - 17.0 - 20.0 1 Rem. 2 - 34.0 - 37.0 0.03 0.03 0.75 - 1.50 0.025 - -



Features:



Prevent corrosion in chloride and fluoride media;
Excellent resistance to chloride and stress corrosion cracking;
Resistant to high temperature;
Great strength and toughness;
High resistivity and expansion rate.

Application:



Used for filter and demister;
Used in flue gas desulfurization, pulp and paper production, pollution control, environmental protection, marine engineering.



Main Specs:

Specification of Hastelloy B woven wire mesh
Mesh (Wires/ in.) Wire diameter (in.) Width of opening (in.) Open area (%)
16 × 16 0.014 0.049 60.2
30 × 30 0.0085 0.025 55.4
30 × 30 0.0106 0.0227 46.5
60 × 60 0.0072 0.009 30.5
200 × 200 0.002 0.003 36



Specification of Hastelloy C276 woven wire mesh
Mesh (Wires/ in.) Wire diameter (in.) Width of opening (in.) Open area (%)
6 × 6 0.047 0.12 51.8
8 × 8 0.032 0.093 55.4
10 × 10 0.025 0.075 56.3
12 × 12 0.023 0.06 51.8
12 × 12 0.016 0.067 64.5
12 × 12 0.015 0.068 66.6
14 × 14 0.02 0.051 51
16 × 16 0.018 0.045 50.7
16 × 16 0.009 0.0535 73.27
20 × 20 0.023 0.027 29.2
20 × 20 0.016 0.034 46.2
20 × 20 0.009 0.041 67.2
24 × 24 0.014 0.028 44.2
30 × 30 0.013 0.02 37.1
30 × 30 0.009 0.024 53.1
40 × 40 0.01 0.015 36
40 × 40 0.009 0.016 41
40 × 40 0.0075 0.018 49
50 × 50 0.009 0.011 30.3
60 × 60 0.0072 0.009 30.5
60 × 60 0.0044 0.0123 54.2
80 × 80 0.007 0.006 19.4
80 × 80 0.001 0.0085 46.2
100 × 100 0.001 0.006 36
120 × 120 T 0.004 0.0043 27
180 × 180 0.002 0.0036 41
200 × 200 0.0023 0.0027 48
200 × 200 0.002 0.003 36



Specification of Hastelloy X woven wire mesh
Mesh (Wires/ in.) Wire diameter (in.) Width of opening (in.) Open area (%)
10 × 10 0.025 0.075 56.3
18 × 18 0.009 0.047 70.4
20 × 20 0.016 0.034 46.2
50 × 50 0.003 0.017 72.3
60 × 60 0.0075 0.009 30.5



There is a filter disc made of hastelloy C-276 wire mesh with stainless steel frame.



Packing:

Inside with a paper core, outside with a piece of waterproof, the in wooden case.
