65mn Vibrating Screen Mesh Panel 30m X 2m For Aggregates Screening

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 10Rolls
Price Negotiable
Packaging Details warp with plastic film and waterproof pater, then in pallets or wooden cases
Delivery Time two weeks
Payment Terms 30% TT in advance, balance before delivery
Supply Ability 2000rolls per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Silver Width Up To 2000mm
Edge Type Cut Edge Weave Type Crimped
Application Usually Used As Quarry Screen In Mine, Quarry And Other Industrial Fields As Sieving, Grading And Separating Screening Materials. Product Name Crimped Wire Mesh
Hoe Shape Square Hole Or Slot Hole Length 30m
High Light

65mn vibrating screen mesh

,

vibrating screen mesh 30m x 2m

,

aggregates vibratory screen mesh

Leave a Message
Product Description

Product Description:

Stainless Steel Crimped Wire Mesh is a type of wire mesh made of high quality stainless steel wire with square or slot hole. It has a great dimensional strength and stability, great resistance to abrasion, uniform openings and excellent anti-corrosion properties, making it suitable for many industrial and commercial applications. It is usually used as a quarry screen in mine, quarry and other industrial fields as sieving, grading and separating screening materials. It is available in different mesh sizes from 10mm to 120mm and wire diameters from 1.0 to 5.5mm.



The stainless steel wire used to make the crimped wire mesh has superior tensile strength and provides higher resistance to corrosion and abrasion, making it ideal for many applications. The crimped wire mesh also offers great dimensional stability and uniform openings which make it ideal for sieving and screening applications. It is also highly resistant to corrosion and is capable of withstanding extreme temperatures.



Stainless Steel Crimped Wire Mesh is widely used in various industries, such as mining, quarrying, chemical, food processing and many others. It is also used for many decorative purposes, such as fencing, partitions, grilles and furniture. It is also used in construction, as a partition or as a guard in walkways and staircases. It is also used as a safety barrier in playgrounds and public places.



Vibration screen mesh For all of mining, aggregate, asphalt mixing and road construction industries, every cent saved from high-quality production, fast parts changes and a longer part wear life will be eventually converted into hard profits and real cost reduction of companies.



Vibration screen mesh As the most important part of vibrating screens, a set of high-quality wire cloth with high accuracy, long wear life and high anti-impact is the foundation of production quality assurance in all industries above.



Features:

  • Product Name: Stainless Steel Crimped Wire Mesh
  • Edge Type: Cut Edge
  • Features: Great Dimensional Strength And Stability, Great Resistance To Abrasion, Uniform Openings And Excellent Anti-corrosion
  • Hole shape: Square Hole Or Slot Hole
  • Aperture: 10mm-120mm
  • Surface Treatment: Polished
  • Weaving after crimping, up to 2000mm width, 1.0 to 5.5mm diameter wire


Technical Parameters:

Property Value
Product Name Crimped Wire Mesh
Width Up to 2000mm
Surface Treatment Polished
Hole Shape Square Hole or Slot Hole
Weave Type Crimped
Length 30m
Application Usually Used As Quarry Screen In Mine, Quarry And Other Industrial Fields As Sieving, Grading And Separating Screening Materials.
Aperture 10mm-120mm
Packing Rolls Or Sheets
Wire Diameter 1.0 to 5.5mm



Wire Diameter

Aperture

Open Area Rate

mm

Inch

mm

Inch

%

10

0.394

2

0.079

69.44

12

0.472

3

0.118

64

15

0.519

2.5

0.098

73.47

20

0.787

3

0.118

75.61

25

0.984

4

0.157

74.32

30

1.181

3

0.118

82.64

40

1.575

5

0.197

79.01

50

1.969

4

0.157

85.73

Generally, the specs are made according to your requirements.



Applications:

Stainless Steel Crimped Wire Mesh, with the brand name TENGLU, is produced in Anping of China and is certified by ISO. The minimum order quantity is 10Rolls and the price is negotiable. Packaging is done with plastic film and waterproof paper, then in pallets or wooden cases. The delivery time is two weeks and payment terms are 30% TT in advance, balance before delivery. The supply ability is 2000rolls per month. The edge type is cut edge and the weave type is crimped. The color is silver and the holes shape is square or slot hole with aperture ranging from 10mm to 120mm.



Customization:

Customized Stainless Steel Crimped Wire Mesh

We provide customized stainless steel crimped wire mesh with high quality and excellent service. Our stainless steel crimped wire mesh is made of carbon iron wire, galvanized steel wire or stainless steel wire with wire diameter from 1.0 to 5.5mm. It is available in square or slot hole, up to 2000mm width. Weaving after crimping, it is widely used in the construction, petroleum, chemical industry, breeding, garden and food processing etc.

Brand Name: TENGLU
Place of Origin: Anping of China
Certification: ISO
Minimum Order Quantity: 10Rolls
Price: Negotiable
Packaging Details: warp with plastic film and waterproof pater, then in pallets or wooden cases
Delivery Time: two weeks
Payment Terms: 30% TT in advance, balance before delivery
Supply Ability: 2000rolls per month
Packing: Rolls Or Sheets
Wire Diameter: 1.0 To 5.5mm
Material: Carbon Iron Wire, Galvanized Steel Wire Or Stainless Steel Wire
Hoe shape: Square Hole Or Slot Hole
Color: Silver

We are committed to providing our customers with the best products and services. Don't hesitate to contact us if you have any inquiries.



Support and Services:

Stainless Steel Crimped Wire Mesh Technical Support and Service

At XYZ, we offer professional technical support and service for our Stainless Steel Crimped Wire Mesh products. Our team of experienced professionals can assist you with any questions or concerns you may have regarding the product and its application.

We provide a comprehensive range of services including product installation and maintenance, troubleshooting, technical advice, and product customization. Our team is available to answer any questions you may have regarding the installation and use of our Stainless Steel Crimped Wire Mesh. We also offer comprehensive after-sales service to ensure that you have the best experience possible with our products.

For any additional information or assistance, please do not hesitate to contact our team of experts. We look forward to helping you with your Stainless Steel Crimped Wire Mesh needs.



Packing and Shipping:

Packaging and Shipping

Stainless Steel Crimped Wire Mesh is securely packaged and shipped. The product is wrapped in plastic and securely fastened to a pallet. The pallet is then wrapped with plastic and securely fastened with plastic straps. It is then loaded onto a truck and shipped to the customer's address.



FAQ:

Q1: What is Stainless Steel Crimped Wire Mesh?

A1: Stainless Steel Crimped Wire Mesh is a kind of mesh that is made of high quality stainless steel wire and formed by a mechanical crimping process. It is corrosion-resistant and rust-proof and is widely used in mining, chemical industry, food industry and other fields.

Q2: What is the Brand Name of Stainless Steel Crimped Wire Mesh?

A2: The Brand Name of Stainless Steel Crimped Wire Mesh is TENGLU.

Q3: Where is the origin of Stainless Steel Crimped Wire Mesh?

A3: The origin of Stainless Steel Crimped Wire Mesh is Anping of China.

Q4: What is the Minimum Order Quantity of Stainless Steel Crimped Wire Mesh?

A4: The Minimum Order Quantity of Stainless Steel Crimped Wire Mesh is 10Rolls.

Q5: What is the Payment Terms and Supply Ability of Stainless Steel Crimped Wire Mesh?

A5: The Payment Terms of Stainless Steel Crimped Wire Mesh is 30% TT in advance, balance before delivery, and the Supply Ability is 2000rolls per month.
