Molybdenum Metal Woven Wire Mesh 2 Mesh To 280 Mesh High Strength Low Elongation

  • Molybdenum Metal Woven Wire Mesh 2 Mesh To 280 Mesh High Strength Low Elongation
  • Molybdenum Metal Woven Wire Mesh 2 Mesh To 280 Mesh High Strength Low Elongation
  • Molybdenum Metal Woven Wire Mesh 2 Mesh To 280 Mesh High Strength Low Elongation
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 2Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features High Strength And Low Elongation Product Name Molybdenum Wire Mesh
Material Molybdenum Wire, Molybdenum Alloy Wire Hole Shapes Square
Woven Type Plain Weave, Twill Weave, Dutch Weave. Mesh Counts 2 Mesh - 280 Mesh
Wire 0.02mm - 4.87mm. Common Width 0.1m - 1.5m.
Common Length 30m Or As Request Application Used In High-temperature Field Such As Furnace, Petroleum, Chemical, Food, Medicine, Machinery And Other Industries For Filtering And Sieving Use.
High Light

molybdenum metal woven wire mesh

,

high strength metal woven wire mesh

,

low elongation woven wire mesh
Leave a Message
Product Description

Molybdenum Wire Mesh 2 Mesh To 280 Mesh High Strength And Low Elongation



Molybdenum Wire Mesh Introduction:



Molybdenum Wire Mesh is a type of woven wire mesh, which is made of pure molybdenum wires or alloy wires. According to the weaving patterns, molybdenum wire mesh has plain weave, twill weave, dutch weave patterns with square and rectangular shaped holes on surface.



Molybdenum wire mesh has high strength and low elongation, excellent electric-conductivity, heat-conducting property. It can also resist corrosion, acid, alkaline, oxidation and other harsh environment. Molybdenum wire mesh can be popularly used in high-temperature field such as furnace, petroleum, chemical, food, medicine, machinery and other industries for filtering and sieving use.



Features:



High tensile strength.
Low elongation.
Acid and alkaline resistant.
Corrosion resistant.
High temperature resistant.
Good electricity-conductivity.
Lightweight.
Various hole shapes.
Excellent filtering performance.

Applications:



Molybdenum wire mesh has corrosion, heat-conductivity and is widely used in high temperature field for sieving and filtering. The main application fields are:

Aerospace.
Nuclear power filed.
Electro-vacuum industry.
Glass furnaces.
Petroleum.
Oil and gas industry.
New energy industries.
Food processing industry.

Materials:

Molybdenum Chemical Composition (%)
C Fe Ni O Si N Mo
0.01 0.01 0.005 0.007 0.01 0.02 Rem


Specifications



Molybdenum Wire Mesh Specification
Mesh/Inch Wire Diameter (mm) Opening (mm) Opening Area % Weight kg/m2 Mesh/Inch Wire Diameter (mm) Opening (mm) Opening Area % Weight kg/m2
1 4.87 20.523 68% 15.4 40 0.25 0.385 37% 1.62
2 3.04 9.652 58% 12 40 0.23 0.401 40% 1.37
2 2.6 10.033 62% 8.78 40 0.22 0.415 43% 1.25
3 2 6.467 58% 7.8 40 0.19 0.445 49% 0.93
3 1.6 6.867 66% 4.99 50 0.19 0.318 39% 1.17
4 1.6 4.75 56% 6.65 50 0.15 0.335 49% 0.73
4 1.2 5.15 66% 3.74 50 0.2 0.478 89% 1.29
5 1.2 3.88 58% 4.67 60 0.15 0.273 42% 0.87
5 1 4.08 65% 3.24 60 0.16 0.263 39% 0.99
6 1.2 3.033 51% 5.61 70 0.12 0.243 45% 0.65
6 0.9 3.333 62% 3.15 80 0.12 0.198 39% 0.74
8 0.61 2.565 65% 1.93 90 0.12 0.162 33% 0.84
10 0.5 2.032 64% 1.62 100 0.1 0.154 37% 0.64
10 0.45 2.083 67% 1.31 100 0.076 0.177 49% 0.37
12 0.5 1.609 58% 1.94 120 0.09 0.122 33% 0.63
14 0.42 1.397 59% 1.6 120 0.08 0.132 39% 0.49
16 0.38 1.212 58% 1.5 140 0.06 0.121 45% 0.32
18 0.28 1.317 65% 0.91 150 0.065 0.104 38% 0.41
20 0.4 0.87 47% 2.07 180 0.06 0.081 33% 0.42
20 0.32 0.955 57% 1.33 180 0.05 0.091 42% 0.29
24 0.28 0.784 55% 1.22 200 0.05 0.077 37% 0.32
24 0.23 0.824 61% 0.82 250 0.04 0.062 37% 0.25
26 0.25 0.723 55% 1.32 270 0.028 0.066 49% 0.13
28 0.27 0.633 49% 1.32 280 0.03 0.061 45% 0.16
28 0.23 0.673 55% 0.96 300 0.04 0.045 28% 0.31
30 0.23 0.613 52% 1.03 325 0.035 0.043 30% 0.25
32 0.3 0.494 39% 1.87 400 0.038 0.038 37% 0.16

Other specifications according to your request.
