Aluminum Alloy 1 To 20 Mesh Metal Square Mesh Corrosion Resistance

Place of Origin Hengshui,China
Brand Name QIANPU
Minimum Order Quantity 10roll
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden cases or pallets.
Delivery Time 2 weeks
Payment Terms T/T, Western Union, L/C
Supply Ability 2300 Meter/Meters per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Features Good Corrosion Resistance In Marine Atmospheres Product Name Crimped Wire Mesh
Mesh Counts 20 Per Inch Material Aluminum Alloy
Type Plain Crimped Weave Hole Sapes Square, Rectangular
Technique Weaving After Crimping Width 1m, 1.5m, 2.0m, Etc
Length 10m, 15m, 20m, 30m, Etc Application For Heating And Drying Equipment In Metallurgy, Etc
High Light

Aluminum Alloy Metal Square Mesh


20 Mesh metal square mesh


1 Mesh metal netting mesh

Leave a Message
Product Description

1 To 20Mesh Counts Lightweight Aluminum Alloy Crimped Wire Mesh

Aluminum is largely considered the most popular non-ferrous metal in the world, and as such, aluminum alloys are commonly used in the wire mesh industry. Aluminum alloys are composed primarily of aluminum, and also contain other elements like copper, magnesium, manganese, or silicon.
Aluminum woven wire mesh is lightweight; in fact, a good rule of thumb is that, when compared to its stainless steel counterpart, aluminum mesh is approximately 1/3rd the weight of stainless. Aluminum wire mesh is also corrosion resistant in most normal environments but will corrode quickly in the presence of alkaline solutions and hydrochloric and hydrofluoric acids. With an estimated melting point of 1218°F, aluminum has many benefits, including a relatively low cost compared to other meshes. Aluminum woven wire mesh is a popular choice for a wide array of industries including aerospace and automotive, as well as marine and electrical conductivity applications.
We specialize in stocking many of the standard or market grades of aluminum in alloy 5052. As indicated in the chart below, the 5000 series of aluminum contains magnesium which is the main secondary element. This inclusion of magnesium serves as a hardener and offers good corrosion resistance in marine atmospheres.



Aluminum Crimped Wire Mesh
Mesh / Inch 1, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, etc.
Wire Diameter 0.2-10mm
Aperture Size 0.70-100 mm
Mesh Counts 1-20 mesh
Rolls or Panels 1mX15m, 1.5mX15m, 2.0mX20m, etc.

Can be customed as your requirements.

Aluminum Alloys:

These are light metals, with good strength to weight ratios. At ordinary
temperatures they resist Nitric and Sulphuric Acids, but corrode quickly in the presence of alkaline solutions and hydrochloric and hydrofluoric acids. Melts at 1218 F.


Alloy Al Cu Fe Mg Mn Si Zn Cr
1100 ≥99.0 0.2 0.06 - 0.05 0.04 0.1 -
5056 93.0-94.5 0.1 0.4 4.5-5.6 0.05-0.2 0.3 0.1 0.05-0.2
6061 96.0-97.0 0.15-0.4 0.7 0.8-1.2 0.15 0.4-0.8 0.25 0.15-0.35


. Corrosion resistant, alkali resistant
. Extremely tough and durable
. Good flexibility & high strength
. Easy to clean
. Light weight



Iron Chromium Aluminum Wire Mesh is also known as FeCrAl wire mesh, heat resistant alloy wire mesh, electric heating alloy wire mesh. It has the characteristics of oxidation resistance, sulfur resistance, anti permeability and excellent heat resistance. This aluminum alloy mesh is a popular heating choice for heating and drying equipment in metallurgy, coal mine, printing and dyeing, electric furnaces, household electric appliances and infrared devices.

Aluminum Crimped Wire Mesh, Aluminum Alloy 1100 / 5056 / 6061, 1-20Mesh Counts


Packed with polyfilm or water proof paper, outside with wooden cases or pallets.
