Closed End Stainless Steel Crimped Wire Mesh 0.1" To 8"

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 1 roll
Price Negotiable
Packaging Details inner kraft, outside plastic cloth, put into wooden pallet or case
Delivery Time 2 weeks
Supply Ability 2300 Meter/Meters per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Product Name Heavy Duty Crimped Wire Mesh Standard AISI, ASTM
Weaving Type Heavy Duty Crimped Technique Woven
Edge Closed Edge, Covered Edge Hole Size 0.1" To 8"
Width 0.5m To 2m Length 30m Or Customized
Feature Strong And Firm Structure Application Vibrating Screen In Ming Industry
High Light

0.1in Closed End Stainless Steel Crimped Wire Mesh


0.1in Stainless Steel Crimped Wire Mesh


0.1in 8in screen mesh stainless steel

Leave a Message
Product Description

Closed End Crimped Vibrating Screen Strong And Firm Structure Crimped Wire Mesh




Iron wire, black wire, stainless steel wire, copper wire and other non-ferrous metal.


2> Weaving:


Pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending.




1) High tension: Much higher tension than common polyester mesh and smooth tension;

2) Super precision: Uniform wire diameter and aperture with extremely low difference;

3) Low elongation: Very small elongation of wire mesh at high tension;

4) High flexibility: The wire mesh will not lose elasticity at extreme tension;

5) High corrosion resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber;



4>common specifications:


Diameter 1.0mm x mesh opening 8mm or 10mm

Diameter 1.5mm x mesh opening 12.5mm, 15mm or 20mm

Diameter 3mm x mesh opening 15mm, 20mm, 30mm

Length and width specifications: 1mX25m 1mX30m 1.2mX25m 1.2mX30m


Wire Gauge
Wire Diameter
Mesh/Inch Aperture
14 2.0 21 1 4.2
8 4.05 18 1 15
25 0.50 20 0.61 2.6
23 0.61 18 0.8 3.4
24 0.55 16 0.1 2.5
24 0.55 14 0.12 4
22 0.71 12 0.14 2.94
19 1 2.3 0.18 1.45
6 4.8 1.2 2 20
6 4.8 1 2 20
6 4.8 0.7 3 14
14 2.0 5.08 0.3 12
14 2.0 2.1 1 2.5
14 2.0 3.6 1.5 1.9


Width of the grid: up to 2.200 mm
Length of the grid: up to 5.000 mm or in roll form up to 50 m
Dimensional tolerances in length and width: -0 mm /+1 mesh width (customary)
On request fixed measures with tolerances of +/-2 mm in length and width

Weaving type:

Plain weave.
Flat top.
Intermediate crimped.
Lock crimped.


Mainly used as screen mesh, it is widely used in many industries, such as mining screen, quarrying screen, the screen deck, screen wire for stone crusher, Classifying Trommel; Vibrating screen; Road construction equipment; The Asphaltum mix round equipment and the mine vibrating screens, chemical industry, pharmacy, machinery, protection, construction.



Closed End Stainless Steel Crimped Wire Mesh 0.1" To 8" 0Closed End Stainless Steel Crimped Wire Mesh 0.1" To 8" 1


About our company


Anping Qianpu Wire Mesh Products Co., a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.

Our product range is as below,

Stainless steel woven wire mesh

Welded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

Wire mesh filter

Window screen


It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.


In order to make an offer,please provide us below wire mesh specification information.


Wire diameter

Mesh size

Wire mesh length

Wire mesh width

If it is possible,please also provide us weight per roll that you required.


Closed End Stainless Steel Crimped Wire Mesh 0.1" To 8" 2


We are specialized in manufacture and export of stainless steel wire mesh product,if you have request please contact us.We will provide professional service and guarantee on time delivery.
