0.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 1 roll
Price Negotiable
Packaging Details inner kraft, outside plastic cloth, put into wooden pallet or case
Payment Terms T/T, Western Union, L/C
Supply Ability 2300 Meter/Meters per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Corrosion Resistance Product Name Stainless Steel Crimped Wire Mesh
Material Stainless Steel Wire Type Crimped Wire Mesh
Weave Style Plain Crimped Wire Diameter 0.5mm To 4.8mm
Technique Woven Applications Fence
Color Bright Silver Surface Treatment Polished
High Light

4.8mm 304 Stainless Steel Mesh Screen For Fence

,

0.5mm 304 stainless steel mesh screen

,

ss304 mesh steel screen

Leave a Message
Product Description

Corrosion Resistance High Temperature Resistant For Fence Crimped Wire Mesh



Material :


iron, carton steel,copper.stainless steel 201,304,316L.

Weave:Copper plain weave crimped wire mesh is woven using wire crimped prior to weaving.
The crimps are made at the points the shute and warp wires intersect which secures the wire,thereby stabilizing the cloth and preventing the wire from inermediate crimp.



Stainless steel/ copper bbq grill net crimped wire mesh Used :



It is widely used in bbq baking grill net, filtering and protection of petroleum, chemical industry and ocean industries with acid and alkali environment.
It is also used for making glass reinforcer, various baskets for life and industrial use, art crafts, baskets used in the kitchen and refrigerator



Specifications:



Wire Gauge Wire Diameter Mesh/Inch Aperture
SWG mm mm
14 2 21 1
8 4.05 18 1
25 0.5 20 0.61
23 0.61 18 0.8
24 0.55 16 0.1
24 0.55 14 0.12
22 0.71 12 0.14
19 1 2.3 0.18
6 4.8 1.2 2
6 4.8 1 2
6 4.8 0.7 3
14 2 5.08 0.3
14 2 2.1 1
14 2 3.6 1.5





0.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 00.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 10.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 20.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 3



Packing:

1.1.Package in the plastic bags them put into the wooden case.
2. Package in the plastic bags then put into the paper box.
3.As customers' requirement.



Features:

  • Corrosion resistance.
  • Anti-acid and alkali
  • Anti-high temperture.
  • Good filter performance.
  • Long using life
  •

Application:

  • In acid, alkali environment conditions sieving and filtering.
  • Petroleum industry as mud mesh,.
  • Chemical fiber industry as screen mesh.
  • Plating industry as acid cleaning mesh.

About our company



Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.

Our product range is as below,

Stainless steel woven wire mesh

Welded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

Wire mesh filter

Window screen



It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.



In order to make an offer,please provide us below wire mesh specification information.

Material

Wire diameter

Mesh size

Wire mesh length

Wire mesh width

If it is possible,please also provide us weight per roll that you required.



0.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 40.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 50.5 To 4.8mm 304 Stainless Steel Mesh Screen For Fence 6



We are specialized in manufacture and export of stainless steel wire mesh product,if you have request please contact us.We will provide professional service and guarantee on time delivery.






3Mesh Single Intermediate Crimped Mesh
Wire Diameter Opening Open Area Rate
mm Inch mm Inch %
3.0 0.1181 5.466 0.2152 41.68
2.6 0.1023 5.866 0.2309 48.01
2.3 0.0905 6.166 0.2427 53.04
2.0 0.0787 6.466 0.2545 58.33
1.8 0.0708 6.666 0.2624 62.00
1.6 0.0629 6.866 0.2703 65.77
1.4 0.0551 7.066 0.2782 69.66
1.2 0.0472 7.266 0.2860 73.66
1.0 0.0393 7.466 0.2939 77.77
0.8 0.0314 7.666 0.3018 81.99
