Heavy Duty Stainless Steel Security Screen Customized Wire Mesh Window Screen
Product Details
| Features | Anti-rust And Heat Resistance | Product Name | Stainless Steel Security Screen |
|---|---|---|---|
| Material | Stainless Steel | Hole Shape | Square Hole |
| Mesh Counts | 10 Mesh × 10 Mesh, 11 Mesh × 11 Mesh, 12 Mesh × 12 Mesh And 14 Mesh × 14 Mesh | Wire Diameter | 0.6 Mm - 1.2 Mm |
| Color | Black, Gray And White. Other Colors Are Also Available At Your Requests. | Width | 750 Mm, 900 Mm, 1000 Mm, 1200 Mm, 1500 Mm. |
| Length | 1500 Mm, 2000 Mm, 2400 Mm, 3000 Mm. | Application | Used For Houses, Hotels, Office Buildings And Schools. It Is Also Suitable For Chemical Industrial District, Marine Environment, Beachfront Cities And Swimming Pool |
| Highlight | heavy duty stainless steel security screen,customized wire mesh window screen,stainless steel security screen mesh |
||
Product Description
Heavy Duty Stainless Steel Security Screen Customized Wire Mesh Window Screen
The specifications of Anti-theft stainless coating window screen
1 . The materials of Anti-theft stainless coating window screen: stainless steel wire (sus 304 314 306 316)
2. Finishing: powder coating
3. Mesh per inch: 11x11 mesh*0.8mm,12x12 mesh*0.7mm,14x14 mesh*0.6mm,14x14 mesh 0.55mm,14x 14 mesh 0.5mm
4. Wire Diameter: 0.8mm 0.7mm 0.6mm 0.55mm 0.5mm
5. Surface treatment: Black powder coated, gray powder coated
6. Standard panel size: 1500mm*3000mm;1300mm*2600mm;1200mm*2000mm;1200mm*2400mm;1000*2400mm;
900mm*2000mm;900mm*2400mm;750mm*2000mm;750mm*2400mm.
7. Packaging: waterproof paper, wooden case
Feature of security
The features of Anti-theft stainless coating window screen
1. Anti-theft stainless coating window screen is equal tensile stainless steel wire and equal wire diameter.
2. Anti-theft stainless coating window screen has equal hole size, flat and straight surface.
3. Anti-theft stainless coating window screen can meet Australia standard, pass knife test, impact test.
4. Anti-theft stainless coating window screen can produced very good sharpness from inside to out, but blurred from outside to inside
5. Anti-theft stainless coating window screen can create a e and comfortable private space, while mosquitoes can’t break into the room
6. Anti-theft stainless coating window screen is a warm room and office space, security, theft-proof, bullet-proof product of choice
7. Anti-theft stainless coating window screen is anti- rust, high temperature resistant
Specification:
|
Material |
Mesh per inch |
Wire Dia (mm) |
Wire Dia (inch) |
Open Area |
|
AISI 316 or 304 |
10 x 10 |
0.9mm |
0.035" |
41.7 |
|
AISI 316 or 304 |
10 x 10 |
1.2mm |
0.028" |
27.8 |
|
AISI 316 or 304 |
10 x 10 |
0.8mm |
0.032" |
46.9 |
|
AISI 316 or 304 |
10 x 10 |
1.15mm |
0.045" |
29.9 |
|
AISI 316 or 304 |
11 x 11 |
0.8mm |
0.032" |
42.5 |
|
AISI 316 or 304 |
11 x 11 |
0.7mm |
0.027" |
48.3 |
|
AISI 316 or 304 |
12 x 12 |
0.7mm |
0.027" |
44.8 |
|
AISI 316 or 304 |
12 x 12 |
0.58mm |
0.023" |
52.8 |
|
Special mesh can be made according to customers requirement |
||||
Application
Security screen is an ideal choice for windows and doors, as a heavy-duty shield, which can effectively protect your home and office. Besides it is also suitable for government departments, commercial office buildings, premium villas and residential areas. This advanced product is often applied to prevent intruders, burglars, storm and other destruction.
Our other related products
Our stainless steel woven wire mesh woven type cover plain weave,twill weave,dutch weave,plain dutch weave,twill dutch weave.
For plain weave,our mesh size range is 1-500 mesh,
twill weave 325×325mesh,
plain dutch 70×400mesh,
twill dutch 400×2800mesh,
reverse dutch weave 720×150mesh.
Our company website is www.stainlesssteelwiremeshfactory.com,our product range also cover following items,
-
stainless steel woven wire mesh
-
welded wire mesh
-
crimped wire mesh
-
hexagonal wire mesh
-
expanded wire mesh
