20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes

  • 20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes
  • 20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 1 roll
Price Negotiable according to quantity of order
Packaging Details 1. inside use carton pipe for support+wire mesh layer+water proof paper 2. outside use plastic wooden bags+wooden case/carton pipes/wooden pallets. 3. also we can as per your requirements.
Supply Ability 3000 rolls per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Dutch Wire Mesh Material Stainless Steel 304 316
Cert ISO9001 Width 0.1 To 2.0m
Length 30m Or Customized Color Silver
Wire Diameter High Corrosion Resistance Application Industrial Filtration
Highlight

20×270 Dutch Weave Wire Mesh

,

Customized Sizes Dutch Weave Mesh

,

Dutch Weave Wire Mesh 20×270
Leave a Message
Product Description

20×270 Reverse Dutch Weave Customized Sizes Stainless Steel Dutch Wire Mesh



Twill Dutch Weave wire cloth

  • High corrosion resistance: stainless steel has the advantage of high wear resistance and corrosion
  • Stable work effect: high-quality products with high-quality raw materials does not readily transform.
  • The product strength: will to work under high working strength.
  • Easy to clean: It has the advantage of convenient cleaning.
  • Product description: Material:Stainless steel wire(SUS302,304,304L,316,316L),nickel wire, brass wire.

Twill Dutch Weave wire cloth

Twill Dutch weave wire cloth combines Dutch and twill weaving to provide a fine mesh filtering cloth. Shute wires are passed over and under two warp wires, providing a tight, fine filter with tapered openings. The weaving process allows for the use of very fine wires, to micron size, producing filtering mesh for gas and liquid applications.



Twill dutch woven



Mesh/Inch (warp×weft) Wire Dia. warp×weft (mm) Normal size (μm) Effective
area%		 Weight kg/sq.m Cloth thickness
(mm)
20×270 0.25×0.2 119 17.6 3.14 0.65
20×200 0.355×0.28 118 12.1 4.58 0.915
24×300 0.28×0.18 110 19.6 3.01 0.64
20×150 0.45×0.355 101 7.5 6.02 1.16
30×340 0.28×0.16 89 17.9 2.84 0.60
30×270 0.28×0.20 77 11.2 3.41 0.68
40×540 0.18×0.10 70 23.5 1.73 0.38
40×430 0.18×0.125 63 15.4 2.09 0.43
50×600 0.125×0.09 51 17.2 1.47 0.305
50×500 0.14×0.11 47 12 1.83 0.364
65×600 0.14×0.09 36 1.59 0.32
70×600 0.14×0.09 31 10.1 1.61
78×760 0.112×0.071 13.5 1.25 0.254
78×680 0.112×0.08 29 10.3 1.37 0.272
80×680 0.112×0.08 28 9.8 1.38
90×850 0.10×0.063 26 12.7 1.12 0.226
90×760 0.10×0.071 24 9.6 1.23 0.242
100×850 0.10×0.063 22 10 1.14 0.226
130×1500 0.063×0.036 21 18.6 0.64 0.135
100×760 0.10×0.071 20 7.4 1.25 0.242
130×1200 0.071×0.045 18 12 0.80 0.161
130×1100 0.071×0.05 17 9.4 0.87 0.171
150×1400 0.063×0.04 15 11.4 0.71 0.143
160×1500 0.063×0.036 12.4 0.67 0.135
165×1500 0.063×0.036 14 11.4
174×1700 0.063×0.032 13 12.9 0.62 0.127
165×1400 0.063×0.04 8.8 0.73 0.143
174×1400 0.063×0.04 11 7.4 0.74
203×1600 0.05×0.032 10 9.3 0.58 0.114
216×1800 0.045×0.03 9.4 0.53 0.105
203×1500 0.056×0.036 9 6.2 0.67 0.128
250×1900 0.04×0.028 8 7.8 0.51 0.096
250×1600 0.05×0.032 3.8 0.63 0.114
285×2100 0.036×0.025 7 7.2 0.44 0.086
300×2100 0.036×0.025 6 6.0
317×2100 0.036×0.025 5 4.7
325×2300 0.036×0.024 4 4.2
363×2300 0.032×0.022 4.5 0.40 0.076
400×2700 0.028×0.02 4.7 0.36 0.068


Delivery Time
We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material. We'll check with our production department for the non-stock items to offer you the exact delivery time and producing schedule.
Mutual Benefit
If the products of our distributors are unmarketable due to the influence by market factors,we will seek customers in the same market or near market who are in need of the products to help the distributors to handle unsalable products.

20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes 0

Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen



20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes 1

20×270 Reverse Dutch Weave Stainless Steel Woven Wire Mesh Customized Sizes 2

It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.

In order to make an offer,please provide us below wire mesh specification information.
Material
Wire diameter
Mesh size
Wire mesh length
Wire mesh width
If it is possible,please also provide us weight per roll that you required.
