Plain Dutch Twill Stainless Steel Woven Wire Mesh AISI 304 304l 316 316l 310 430 For Filtration
| Place of Origin | Anping of China |
|---|---|
| Brand Name | QIANPU |
| Certification | ISO |
| Minimum Order Quantity | 1 roll |
| Price | Negotiable according to quantity of order |
| Packaging Details | 1. inside use carton pipe for support+wire mesh layer+water proof paper 2. outside use plastic wooden bags+wooden case/carton pipes/wooden pallets. 3. also we can as per your requirements. |
| Supply Ability | 3000 rolls per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Good Wear-resistance, Heat-resistance, Acid-resistance, Corrosion Resistance And Characteristics. | Product Name | Stainless Steel Dutch Wire Mesh |
|---|---|---|---|
| Material | Stainless Steel 304 304l 316 316l 310 430 | Cert | ISO9001 |
| Width | 0.1 To 2.0m | Length | 30m Or Customized |
| Color | Silver | Application | Filtration |
| Highlight | 310 Stainless Woven Wire Mesh,Plain Dutch Twill stainless woven mesh,Filtration 430 stainless woven mesh |
||
Product Description
AISI 304 304l 316 316l 310 430 Plain Dutch Twill Stainless Steel Woven Wire Mesh For Filtration
Material: Made with high-quality stianless steel wire: SUS304, 304L, 316, 316L. or product in brass wire, nickel wire, and if you need other metal materials we also can in accordance with your quantity.
Weave ways: divided Dutch Plain Weaving, Dutch Twill Weaving or Dutch Reverse Weaving.
Dutch Twill Weave: Each weft wire passes alternately over two, and then under two successive warp wires and each warp wire passes alternately over two and under two successive weft wires. It is possible to be used to allow a heavier than standard wire diameter.
Dutch Reverse Weave: Dutch Reverse Weave is the same as Dutch weave except the warp and weft wires are reversed.
Featute: Good wear-resistance, Heat-resistance, Acid-resistance, Corrosion resistance and characteristics.
Application: The prodcution is mainly applied to filter chemical industry, medicine, petroleum, telecom-communication, scientific research units or other applications.
| Dutch Wire Cloth Plain Woven | ||||
| Gauge No. | Mesh/Inch (Warp x Weft) |
Wire Diameter (Warp x Weft) |
Reference Aperture (um) | Weight/sq (kg) |
| 32# | 8 x 62 | 0.63mm x 0.45mm | 300 | 5.42 |
| 40# | 10 x 79 | 0.50mm x 0.355mm | 250 | 3.16 |
| 48# | 12 x 64 | 0.58mm x 0.40mm | 280 | 2.9 |
| 55# | 14 x 88 | 0.40mm x 0.30mm | 180 | 2.54 |
| 76# | 19 x 140 | 0.315mm x 0.20mm | 140 | 1.88 |
| 80# | 20 x | 0.35mm x 0.20mm | - | 3.6 |
| 95# | 24 x 300 | 0.355mm x 0.25mm | 120 | 2.45 |
| 100# | 25 x 140 | 0.28mm x 0.20mm | 100 | 1.95 |
| 120# | 30 x 150 | 0.25mm x 0.18mm | 80 | 1.68 |
| 140# | 35 x 175 | 0.224mm x 0.16mm | 71 | 1.52 |
| 160# | 40 x 200 | 0.20mm x 0.14mm | 60 | 1.40 |
| 180# | 45 x 250 | 0.16mm x 0.112mm | 56 | 1.09 |
| 200# | 50 x 250 | 0.14mm x 0.11mm | 53 | 1.04 |
| 220# | 55.5 x 280 | 0.14mm x 0.10mm | 50 | 0.92 |
| 240# | 65 x 330 | 0.11mm x 0.08mm | 36 | 0.71 |
| 280#(1) | 70 x 350 | 0.11mm x 0.08mm | 35 | 0.72 |
| 280#(2) | 70 x 385 | 0.11mm x 0.07mm | 32 | 0.75 |
| 300# | 78 x 700 | 0.11mm x 0.08mm | 30 | 1.39 |
| 315#(1) | 80 x 400 | 0.10mm x 0.065mm | 40 | 0.62 |
| 315#(2) | 80 x 600 | 0.10mm x 0.06mm | - | - |
| 315#(3) | 80 x 800 | 0.15mm x 0.04mm | - | - |
| Roll width: 1-1.6m | ||||
| Dutch Wire Cloth Twill Woven | ||||
| Gauge No. | Mesh/Inch (Warp x Weft) |
Wire Diameter (Warp x Weft) |
Reference Aperture (um) | Weight/sq (kg) |
| 320# | 81 x 780 | 0.10mm x 0.07mm | 30 | 1.22 |
| 354# | 90 x 550 | 0.12mm x 0.05 | - | - |
| 360# | 91 x 787 | 0.10mm x 0.10 | 25 | 1.24 |
| 400# | 101 x 900 | 0.10mm x 0.10 | 20 | 1.22 |
| 472# | 120 x 400 | 0.10mm x 0.10 | - | - |
| 500# | 127 x 1100 | 0.07mm x 0.07 | 17 | 0.81 |
| 630# | 160 x 1500 | 0.063mm x 0.063 | 15 | 0.62 |
| 650#(1) | 165 x 400 | 0.017mm x 0.017 | - | - |
| 650#(2) | 165 x 600 | 0.017mm x 0.017 | - | - |
| 650#(3) | 165 x 800 | 0.017mm x 0.017 | 25 | - |
| 650#(4) | 165 x 1100 | 0.017mm x 0.017 | - | - |
| 650#(5) | 165 x 1400 | 0.017mm x 0.017 | 16 | 0.76 |
| 685# | 174 x `700 | 0.063mm x 0.063 | 13 | 0.61 |
| 787#(1) | 200 x 600 | 0.071mm x 0.071 | - | - |
| 787#(2) | 200 x 800 | 0.071mm x 0.071 | - | - |
| 787#(3) | 200 x 1400 | 0.071mm x 0.071 | 12 | 0.8 |
| 795# | 202 x 1760 | 0.05mm x 0.05 | 10 | 0.6 |
| 850# | 216 x 1860 | 0.045mm x 0.045 | 9 | - |
| 1000# | 254 x 2000 | 0.04mm x 0.04 | 8 | 0.5 |
| 1125# | 285 x 2235 | 0.036mm x 0.036 | 7 | - |
| 1228# | 312 x 2100 | 0.035mm x 0.035 | - | - |
| 1250# | 318 x 2235 | 0.036mm x 0.036 | - | - |
| 1280# | 325 x 2300 | 0.035mm x 0.035 | 5 | 0.45 |
| 1575# | 400 x 33100 | 0.035mm x 0.035 | 3 | - |
| Roll width: 1-1.6m | ||||
Delivery Time
We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material. We'll check with our production department for the non-stock items to offer you the exact delivery time and producing schedule.
Mutual Benefit
If the products of our distributors are unmarketable due to the influence by market factors,we will seek customers in the same market or near market who are in need of the products to help the distributors to handle unsalable products.
Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen
It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.
In order to make an offer,please provide us below wire mesh specification information.
Material
Wire diameter
Mesh size
Wire mesh length
Wire mesh width
If it is possible,please also provide us weight per roll that you required.
