Ss304 Ss316 Stainless Steel Security Screen Mesh DIN

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 150 square meters
Price Negotiable
Packaging Details Inside 1 roll seperately in waterproof paper then packed it inside of wooden carton
Delivery Time 25days
Payment Terms T/T, Western Union, L/C
Supply Ability 30 0000 square meters per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Product Name Stainless Steel Security Screen Mesh Security Screen Material Stainless Steel 304 316
Standard AISI, DIN Mesh 10*10 14*14 16*16 18*18 22*22 24*24
Treatment Powder Coated, Epoxy, Etc Color Silver, Black, Greym, Etc
Width 1m, 1.2m, 1.5m Or Customized Length Standard 30 Meters
Feature It Has Extremely Solid Structure, Which Is Bullet, Knife, Scissors, Hammer And Almost All Tools Proof Application Window Application, Door Application
High Light

DIN stainless steel security screen mesh


ss316 stainless steel security screen mesh


ss 304 stainless steel security screens

Leave a Message
Product Description

SS304 SS316 Security Screen Impossible To Break Through With Any Tools
security screen intorduction:

Security screen is made of different grade of stainless steel material, including SS 201, SS 304 and SS 316. The SS wires are plain weaved into square meshes in 10 mesh to 14 mesh. The thicker wire diameter, small meshes and durable materials ensures high tensile strength, corrosion and rust resistance, chemical stability performance. And most of all, it has extremely solid structure, which is bullet, knife, scissors, hammer and almost all tools proof. It is nearly impossible to break through with any tools except key.




SS 304 Security Screen
Material: 304 grade stainless steel.
Wire diameter: 0.9 mm (0.035").
Mesh hole opening: 11 mesh × 11 mesh, 12 mesh × 12 mesh, 14 mesh × 14 mesh.
Surface treatment: black powder coated.
Color: black, gray.
Length: 2000 mm, 2400 mm, 3000 mm.
Width: 750 mm, 900 mm, 1000 mm, 1200 mm, 1500 mm.
Guarantee: ten years.
Other mesh size available according to customers' need.

SS 316 Security Screen
Material: 316 marine grade stainless steel wire.
Wire diameter: 0.8 mm.
Mesh hole opening: 11 mesh × 11 mesh, 1.5 mm × 1.5 mm.
Finish: black polyester coated (engineered corrosion and moisture resistant).
Other available size: 14 mesh × 0.5 mm, 14 mesh × 0.6 mm, 12 mesh × 0.7 mm, 10 mesh × 0.9 mm, 8 mesh × 1.0 mm.
Panel width: 750 mm, 900 mm, 1200 mm, 1500 mm.
Panel length: 2000 mm, 2400 mm, 3000 mm.


Material Chemical Composition:


Chemical composition of stainless steel wire:
Grade Chemical Composition(%)
  C Si Mn P S Ni Cr Mo
304 =0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304H >0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304L =0.030 =1.00 =2.00 =0.045 =0.030 9.00~13.50 18.00~20.00 -
316 =0.045 =1.00 =2.00 =0.045 =0.030 10.00~14.00 10.00~18.00 2.00~3.00
316L =0.030 =1.00 =2.00 =0.045 =0.030 12.00~15.00 16.00~18.00 2.00~3.00
430 =0.12 =0.75 =1.00 =0.040 =0.030 =0.60 16.00~18.00 -
430A =0.06 =0.50 =0.50 =0.030 =0.50 =0.25 14.00~17.00 -

Specification of stainless steel wire mesh:


Material Mesh per inch Wire Dia (mm) Wire Dia (inch) Open Area
AISI 316 or 304 10 x 10 0.9mm 0.035" 41.7
AISI 316 or 304 10 x 10 1.2mm 0.028" 27.8
AISI 316 or 304 10 x 10 0.8mm 0.032" 46.9
AISI 316 or 304 10 x 10 1.15mm 0.045" 29.9
AISI 316 or 304 11 x 11 0.8mm 0.032" 42.5
AISI 316 or 304 11 x 11 0.7mm 0.027" 48.3
AISI 316 or 304 12 x 12 0.7mm 0.027" 44.8
AISI 316 or 304 12 x 12 0.58mm 0.023" 52.8
Other specifications can also be customized



Excellent resistance to corrosion and impact.
Quality meets the demands of GB/T 1220–2007 Stainless Steel Rod standard grade.
Good privacy protection and aesthetic effect.
Easy to install with flat and straight surface.
Good air circulation & high quality daylighting.

Packaging & Payment term:

Package:Water proof inside and then wood box out side.
Payment term:T/T 30% advance payment
Delivery Time:25days
Characteristic of stainless steel window screen:

(1) shape: like iron plate -- hard, safe ,Strong resistance to protect hitting
(2) Good light transmission Watching high-definition from the inside, from the outside looking blurred
(3) Prevent mosquitoes, theft
(4) Good stability, rust prevention, alkaline prevent, no afraid of damp and sun
(5) Ease of care: easy to clean dirty with a vacuum cleaner, absorbent sponge or brush
Application of stainless steel window screen:


Security screen can be following places

Private residences.
Military sites.
Commercial kitchens.
Shopping market.
Door application.

Single/double sliding doors.
Hinged doors.
French doors.
Bi-fold doors.
Window application

Double or single sliding windows.
Awning windows.
Quick escape windows.
Pool fencing or balustrade.
French window.
Fixed window.


Why we recommend security screen?

Extremely solid structure. It is considered the most durable and solid structure so far. It is knife proof, scissor proof, hammer proof and even bullet proof. It's no way to attempt to break it and steal.
Save insurance cost. You will not worry thieves intrude your home and steal your expensive properties, so it can save part of insurance for you.
Suitable for coastal environments. The durable stainless steel material is chemical and weather stability. It can be used in the salty, rainy and other harsh environments for long service life and good performance.
Wind resistance. The security screen can provide effective protection from hurricane force winds and protect your properties.
Protect children' safe from window. Traditional insect screen offers little protection for children. Security screen is high strength to protect your children from falling from dangerous window.
Blocks harmful UV rays. The small meshes can help to filter harmful UV rays and protect families' safety.
Pest protection. The security screen can prevent mosquitoes, flies, moths and other small insects from entering home.
Ensure good air circulation. Even if the mesh size is small, but it will not blocks the fresh airs, you can enjoy the fresh air and protect your properties at the same time.
Energy saving. Security screen can allow you enjoy the fresh air and natural ventilation rather than air conditioning.
Architectural appeal. The security screen can supply various colors to suit your exterior and interior environments.
