Insect Proof Galvanized Fly Mesh Window Screen Fabric Type AISI

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5Rolls
Price Negotiable
Packaging Details Inside 1 roll seperately in waterproof paper then packed it inside of wooden carton
Delivery Time 2 weeks
Payment Terms T/T, Western Union, L/C
Supply Ability 30 0000 square meters per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Super Resistance To Impact, Bulletproof, Anti-theft, Anti-fly, Etc Product Name Stainless Steel Security Screen Mesh
Security Screen Material Galvanized, Stainless Steel Standard AISI, DIN
Mesh Size 6 Mesh To 24mesh Weaving Methods Plain Weave
Color Black, White, Grey, Etc Width 1m, 1.2m, 1.5m Or Customized
Length Standard 30 Meters Usage Widely Available At Hardware And Home Improvement Stores
High Light

insect proof galvanized window screen

,

AISI galvanized window screen

,

AISI galvanized steel insect screen

Leave a Message
Product Description

Galvanized Fly Mesh Window Screen Introduction and Fabric Type

Introduction:



A window screen, insect screen or fly screen mesh is a metal wire, fiberglass, or other synthetic fiber mesh, stretched in a frame of wood or metal, designed to cover the opening of an open window. Its primary purpose is to keep leaves, debris, insects, birds, and other animals from entering a building or a screened structure such as a porch, while permitting fresh air-flow. Most houses in Australia, the United States and Canada have screens on all operable windows, which are most useful in areas that have large mosquito populations. Formerly, screens in North America were usually replaced with glass storm windows in the winter, but now the two functions are usually combined in combination storm and screen windows, which allow glass and screen panels to slide up and down.



Specifications:



Material: 316L, 316, 316L, 304, hot-dip galvanizing,manganese steel etc.
Wire diameter: 0.5mm,0.6mm,0.7mm,0.8mm,0.9mm,1.0mm.
Mesh number: 10,11,12,14.
Width: 1m,1.2m,1.3m,1.5m;
Length: 2m,2.2m,2.4m,2.6m,2.8m,3m.
Roll:
Width: 0.5m,0.75m,0.9m,1m,1.2m,1.3m,1.5m;
Length: 10m,15m,20m,30m.




Main material: galvanized, copper, 304, 316 stainless steel, fiberglass, etc.
Surface treatment: black powder coated.
Weaving methods: plain weave or crimped wire woven.







A white and a bluish galvanized window screen on the white background.





304/316 Stainless steel Security Window Screen benefits:



Keep mosquitoes out, let fresh air in, give you a cool and safe house in summer.
Blocks Out at least 30% of UV rays. Means a longer life for interior furnishings.
Blocks heat transfer, improves the energy rating of glass windows and keeps your home cooler in summer and warmer in winter.
Maximizes strength and durability, and enjoy clear unobstructed views.
Corrosion resistant, and 10 year warranty.



Types window screen:



The most common materials used for insect screening material are aluminum and fiberglass. Aluminum window screen is generally available in natural aluminum or in an applied charcoal color; the charcoal is much less visible. Fiberglass is available in light gray as well as charcoal colors, the charcoal again offering better viewing and appearance. Fiberglass is less expensive, and has the advantage of not "denting" when hit or pushed. However, the fiberglass mesh is somewhat more opaque than aluminum mesh, which darkens the external appearance of the window and reduces the amount of light transmitted from outside. In addition, fiberglass screen degrades rapidly with exposure to UV light, leading to it fraying and breaking after just a few years, unlike aluminum which lasts considerably longer.
For applications requiring greater strength, such as screened doors, nylon and polyester screening are also available.
Bronze insect screening is much more expensive, but gives much longer service than either aluminum or fiberglass. When first installing window screen, it has a bright gold color; this weathers to an unobtrusive dark charcoal within a year or less. Bronze is somewhat more resistant to denting than aluminum. Less common screen fabrics include copper, brass, stainless steel, and galvanized steel.
In addition to insect screening, denser screen types that also reduce sunlight and heat gain are available. These offer significant potential energy savings in hot climates.
Do-it-yourself screen and frame replacement kits are widely available at hardware and home improvement stores. These frames are usually composed of straight aluminum sides (which can be cut to size) and plastic corner inserts. Screen replacement kits usually consist of a roll of nylon screening fabric and a generous supply of rubber spline.



Mesh Size/Width (mm) Wire Diameter (mm) Width (mm)
0.056 0.04 1000
0.16 0.08 1000
0.16 0.12 1000
0.2 0.16 1000
0.25 0.2/0.22 1000
0.32 0.16 1000
0.4 0.2 1000
0.4 0.25 1000
0.45 0.2 1000
0.5 0.2 1000
0.5 0.25 1000
0.5 0.3 1000
0.63 0.25 1000
0.63 0.32 1000
0.7 0.32 1000
0.8 0.32 1000
1.0 0.25 1000
1.0 0.32 1000
1.2 0.32 1000
1.2 0.4 1000
1.4 0.45 1000
1.8 0.7 1000
2.0 0.4 1000
2.0 0.5 1000
2.0 0.6 1000
2.0 1.2 1000
2.2 0.45 1000
2.2 0.7 1000
2.5 0.5 1000
2.8 0.9 1000
3.0 1.0 1000
3.2 0.8 1000
3.2 1.2 1000
4.0 1.0 1000
4.0 1.2 1000
4.0 1.6 1000
5.0 0.7 1000
5.0 1.2 1000
5.0 2.0 1000
6.0 1.2 1000
10.0 2.0 1000
12.0 2.0 1000


Application:



Security screen is an ideal choice for windows and doors, as a heavy-duty shield, which can effectively protect your home and office. Besides it is also suitable for government departments, commercial office buildings, premium villas and residential areas. This advanced product is often applied to prevent intruders, burglars, storm and other destruction.



Insect Proof Galvanized Fly Mesh Window Screen Fabric Type AISI 1Insect Proof Galvanized Fly Mesh Window Screen Fabric Type AISI 2







Our other related products



Insect Proof Galvanized Fly Mesh Window Screen Fabric Type AISI 3Insect Proof Galvanized Fly Mesh Window Screen Fabric Type AISI 4



We are a professional wire mesh company, which mainly produce stainless steel woven mesh, square wire mesh, dutch wire mesh, stainless steel ultra-thin mesh, reverse dutch woven cloth, five-heddle dutch woven cloth, sintered wire mesh, crimped wire mesh, stainless steel printing screen, stainless steel security screen, knitted wire mesh, stainless steel wire, nickel wire mesh, brass wire mesh, black wire cloth, epoxy wire mesh, stainless steel welded mesh, shale shaker screen ,steel frame screen, wedge wire screen, water well screen, wave type screen,balanced belt, spiral conveyor belt, ladder belt, double spiral belt, sani grid belt, wire ring belt, flat wire belt,compound balanced belt, filter elements, filter disc and filter tube. We win customers at home and abroad with excellent and high-quality products and service.
