Hot Dipped Galvanized Euro Fence 200mm X 50mm Hole 4.2mm Wire 2.08m X 2.5m Size
Place of Origin | Anping of China |
---|---|
Brand Name | QIANPU |
Certification | ISO |
Minimum Order Quantity | 50Rolls |
Price | Negotiable |
Packaging Details | Warpped with plastic film, then in wooden case or pallets; ; Or as requirements. |
Delivery Time | 2weeks |
Payment Terms | T/T, Western Union, L/C |
Supply Ability | 3000rolls per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xFeatures | High Strength, Corrosion And Rust Resistance. | Product Name | Eurofence, 3D Wire Mesh Fence |
---|---|---|---|
Material | Galvanized Wire, Pvc Coated Wire | Type | Welded |
Wire Diameter | 4.2mm | Hole Size | 200mm X 50mm |
Size | 2.08m X 2.50m | Applications | Construction Sites |
Highlight | hot dipped galvanized euro fence,200mm x 50mm hole euro fence,4.2mm wire euro style fence |
Hot Dipped Galvanized Eurofence 200mm X 50mm Hole 4.2mm Wire 2.08m X 2.5m Size
Introduction:
3D security fence, also called curvy security fence, curved security fence, it is a high security fence which is widely used in airport, factory, residence and other places. The 3D security fence provides strong, durable and flexible structure. The opening of 3D security fence is closely, which supplies high strength and prevents predators from entering the unwanted areas.
The 3D security fence is manufactured from zinc coated steel wire or PVC coated steel wire. There are different curve quantities on the security fence panel according to different height. The installation of 3D security is easy. They can be connected by different types of posts, such as peach post, round post, rectangular post and square post. The 3D security fence can not only be installed on the earth, it can also be installed on the concrete ground for different applications.
3D Wire Mesh Fencing is a welded mesh panel fence that is manufactured by welding steel wires together using electrical fusion. The fence features v-shaped bends along its panels, providing it with additional rigidity and stability.
WE offering our customers a wide selection of high-quality building materials.
Surface Treatment:
Available in galvanized, powder-coating and PVC-coated
1. Electric Galvanized Then PVC Coated
2. Electric Galvanized Then Powder Coated
3. Hot Dipped Galvanized Then PVC Coated
4. Hot Dipped Galvanized Then Powder Coated
5. Hot Dipped Galvanized
Features:
· Anti-climb
The structure of the fence makes it hard for intruders to have a handhold, discouraging them from climbing into unauthorised areas.
· Anti-cut
The anti-cut property of the fence makes it difficult for intruders to cut through the wires and trespass onto the area.
· High tensile strength
This allows the fence to withstand harsh conditions without breaking.
· Good visibility
The mesh structure of the fence provides an unimpaired view of the surroundings. This is particularly important for clear camera surveillance in high security areas.
· Prevents small animals from slipping through the fence
Application:
· Airport terminals
· Schools
· Army camps
· Prison
· Storage depots
· Factories
Specifications
DIMENSIONS (mm) | ||||||
Fence Height | post height | fence width | V bending | wire diameter | mesh | mesh |
630 | 1100 | 2500 | 2 | 4 | 200X55 | 150X50 |
830 | 1300 | 2 | 5 | |||
1030 | 1500 | 2 | ||||
1230 | 1800 | 2 | ||||
1530 | 2000 | 3 | ||||
1830 | 2300 | 4 | ||||
2030 | 2500 | 4 | ||||
2430 | 3000 | 4 |
