0.035" 0.047" Wire SS Welded Wire Mesh SS316L 3Mesh 3 Holes Per Inch

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 20 days
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Features Firm Structure Material SS304 Or SS316
Color Bright Silver Type Welded
Hole Shape Square Hole Mesh Counts 3mesh
Wire Diameter 0.047" Opening 0.2860"
Number Of Holes 3 Holes Per Inch Application Guarding
High Light

0.047" SS Welded Wire Mesh


SS Welded Wire Mesh SS316L


0.047" stainless welded wire mesh

Leave a Message
Product Description

3Mesh 3 Holes Per Inch 0.035" 0.047" Diameter Wire Stainless Steel Welded Wire Mesh


Brief Introduction


Stainless Steel Welded Wire Mesh

When welded wire mesh is made, spools of wires are threaded into a weld mesh machine, much like threading wires into the heddle frames and reed of a woven wire loom. Separate spools of wire are then fed through a straightener and pre-cut to match the desired width of the mesh.


As the machine runs, the wires from the spools are fed through the machine. The pre-cut wires are then placed into a mechanism that lays them across the wires being fed from the spools.


After being laid in place, the machine applies a uniform weld at each cross-section simultaneously. Depending on the length of the welded wire mesh panel, the mesh is made available in welded wire mesh rolls or operators take the mesh, cut the access material, and place it into piles of cut-to-size pieces.


Common Material:


SS304, SS304L, SS316, SS316L. Stainless steel in other alloy are availble.


Features:  Steady construction, good corrosion resistance and oxidation resistance, etc.


Easy to clean;

Easy to install;

Strong structure;

Beautiful outlook;

Corrosion resistance;

Acid resistance;

Alkali resistance;

Wear resistance;

Flat surface;

Solid structure, strong integrity, even if the cut or in part under pressure not loose or slack.




Welded Iron Wire Mesh serves as guards in buildings and factories, animal enclosure and Iron wire mesh fences in agriculture; Welded Iron wire mesh also serves in horticulture industry as guards for trees and plants.




1) Clear Opening. Sample: 1" Opening = a 1" opening, measured from inside wire edge to inside wire edge.

Stainless Steel Welded Wire Mesh Specifications
Clear Opening Wire Diameter Opening
4″Opening 0.250″ 4.000″
3″Opening 0.250″ 3.000″
3″Opening 0.187″ 3.000″


2) Mesh Counts(Meshes/Inch). Sample: 2 Mesh = a total of 2 equal openings within a 1" measurement, from center to center of wire.

Stainless Steel Welded Wire Mesh Specifications
Mesh Counts Wire Diameter Opening
2 0.063″ 0.437″
2 0.047″ 0.453″
2 0.041″ 0.459″
2 0.035″ 0.465″
3 0.047″ 0.286″
3 0.038″ 0.295″
4 0.047″ 0.203″
4 0.032″ 0.218″
4 0.028″ 0.222″


3) Mesh Size(Center to Center). 1" Mesh = a 1" measurement from center to center of wire.

Stainless Steel Welded Wire Mesh Specifications
Mesh(Center to Center) Wire Diameter Opening
2″×2″ 0.250″ 1.750″
0.192″ 1.808″
0.187″ 1.813″
0.162″ 1.838″
0.148″ 1.852″
0.135″ 1.865″
0.120″ 1.880″
0.105″ 1.895″
0.080″ 1.920″
0.063″ 1.937″
2″×4″ 0.105″ 1.895″×3.895″
1″×2″ 0.080″ 0.920″×1.920″
1″×1-1/2″ 0.612″ 1.338″
0.135″ 1.365″
0.120″ 1.380″
1″×1″ 0.148″ 0.852″
0.135″ 0.865″
0.120″ 0.880″
0.105″ 0.895″
0.080″ 0.920″
0.063″ 0.937″
0.047″ 0.953″
0.022″ 0.978″

Other "Mesh Size", "Mesh Counts", "Wire Diameter", "Opening" as your requests.




0.035" 0.047" Wire SS Welded Wire Mesh SS316L 3Mesh 3 Holes Per Inch 0




in waterproof paper in rolls. Custom packing available at request.
