Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage

  • Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage
  • Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage
  • Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50m length
Price Negotiable
Packaging Details Warpped with plastic film, then in wooden case.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Rope Mesh Material Stainless Steel Rope
Weave Type X-Type Width 0.2m To 3.0m
Common Length 30m, 100m Applications Architecture Applications, For Staircases, Facades And Ceilings.
Highlight

0.2m Stainless Steel Rope Mesh

,

X Type Stainless Steel Rope Mesh
Leave a Message
Product Description

Stainless Steel Rope Mesh With Square Openings Decoration and ety Usage



Stainless Steel Rope Mesh


Stainless steel square rope mesh is a new kind of rope mesh which is made of high quality stainless steel ropes in modern society. And it is mainly used as stainless steel decoration mesh because of its square openings which are the symbolization of elegance and beauty. Many people choose stainless steel square rope mesh to decorate their houses and a growing number of halls. Stainless steel square rope mesh is not only used for decoration, but it is also used in many other aspects, such as slope protection rope mesh.


Specifications:



Structure: 7×7

Specifications of X-Type Rope Mesh(7×7)

Cable Diameter

(mm)

Opening Size

MW×MH

(mm)

 Transparency (%)

Weight

(kg/㎡)

Min. Tensile Strength

(KN)
1.0 25×43 88.4 0.91 0.63
1.0 30×52 90.6 0.68 0.63
1.0 35×61 92.0 0.54 0.63
1.0 40×69 93.3 0.44 0.63
1.0 50×87 94.8 0.32 0.63
1.0 60×104 95.8 0.25 0.63
1.0 70×121 96.4 0.20 0.63
1.0 80×139 96.9 0.17 0.63
1.5 25×43 82.6 1.71 1.55
1.5 30×52 85.9 1.31 1.55
1.5 40×69 89.9 0.87 1.55
1.5 50×87 92.2 0.64 1.55
1.5 60×104 93.7 0.50 1.55
1.5 70×121 94.6 0.41 1.55
1.5 80×139 95.3 0.35 1.55
1.5 100×173 96.3 0.27 1.55
1.5 120×208 97.0 0.22 1.55
1.5 140×242 95.5 0.18 1.55
1.5 160×277 97.8 0.15 1.55
1.5 180×312 98.0 0.14 1.55
2.0 40×69 86.1 1.45 2.75
2.0 50×87 89.3 1.07 2.75
2.0 60×104 91.4 0.85 2.75
2.0 70×121 92.6 0.70 2.75
2.0 80×139 93.6 0.60 2.75
2.0 100×173 95.0 0.45 2.75
2.0 120×208 95.9 0.36 2.75
2.0 140×242 96.6 0.30 2.75
2.0 160×277 97.1 0.26 2.75
2.0 180×312 97.5 0.23 2.75
2.0 200×346 97.8 0.20 2.75
Note: α=60°



Structure: 7×19

Specifications of X-Type Rope Mesh(7×19)

Cable Diameter

(mm)

Opening Size

MW×MH

(mm)

 Transparency (%)

Weight

(kg/㎡)

Min. Tensile Strength

(KN)
3.0 50×87 85.2 2.48 5.12
3.0 60×104 87.1 1.94 5.12
3.0 70×121 89.0 1.59 5.12
3.0 80×139 90.5 1.34 5.12
3.0 100×173 92.6 1.01 5.12
3.0 120×208 93.9 0.81 5.12
3.0 140×242 94.9 0.68 5.12
3.0 160×277 95.6 0.58 5.12
3.0 180×312 95.9 0.51 5.12
3.0 200×346 96.3 0.45 5.12
4.0 200×346 95.0 0.70 5.12
Note: α=60°



Dimond Opening Sizes: 25mm to 200mm(MW), 43mm to 436mm(MH); 60

Cable Diameters: 1.0 mm to 4.0 mm.

Roll Width: 0.2m, 0.6m, 1.0m, 1.2m, 2.0m, 3.0m.

Roll Length: 2m, 10m, 15m, 30m.



Other specifications according to your requirements.





Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage 0



Materials:



Stainless Steel 201, 202; 304, 304L, 316, 316L, 321; 410, 420, 430. The commonly constructed materials are 304 and 316 stainless steel.



Features:



Smooth surface and pretty appearance.
Good softness, not hurt hands.
Excellent flexibility for its customized width, length, shape, rope diameter as well as opening size.

High flexibility.
High strength.
Resistant to corrosion.
High durability, maintenance-free and repeated use.



Applications:

Can be used as bridge railing Mesh, helideck mesh, balcony mesh, stairs, green wall, slop protection, zoo mesh, etc.

In LED applications, as support part;

In zoo applications, for security screen of animal cages and enclosures;

In architecture applications, for green wall, parking, bridges, staircases, facades and ceilings.



Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage 1

Packing: Warpped with plastic film, then in wooden case.



Stainless Steel Rope Mesh With Square Openings Decoration And ety Usage 2
