Corrosion Resistance Monel 400 Wire For Sea Water Applications

  • Corrosion Resistance Monel 400 Wire For Sea Water Applications
  • Corrosion Resistance Monel 400 Wire For Sea Water Applications
  • Corrosion Resistance Monel 400 Wire For Sea Water Applications
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 500 kgs
Price Negotiable
Packaging Details Standard sea-worthy package or as required.
Delivery Time 2 weeks
Payment Terms T/T, Western Union, L/C
Supply Ability 18000 tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Excellent Corrosion Resistance In A Wide Range Of Acidic & Alkaline Environments Name Monel 400 Wire
Wire Diameter 0.02mm To 5mm Shape Round Wire
Length Reuqired Application Marine Engineering, Chemical Processing
Highlight

monel 400 wire

,

corrosion resistance monel 400 wire

,

sea water monel 400 wire
Leave a Message
Product Description

Monel 400 Wire Excellent Corrosion Resistance Good For Sea Water Applications

Introduction:



Monel wire is an alloy made of nickel and adding other elements such as copper, iron and manganese. Monel wire has good corrosion resistance and is silvery white, which is suitable for edge wire materials. Monel 400 wire is the corrosion-resistant alloy with the largest amount, the most versatile and excellent comprehensive performance. The alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas media, and excellent corrosion resistance to hot concentrated alkali liquor.



Some characteristics of Monel 400 wire cloth which dictate its wide use are:

Solid solution nickel-copper alloy.
At or below room temperature, it is somewhat-magnetic when annealed.
Above room temperature, it is non-magnetic (depending on composition impurities) when annealed.
Withstands outdoor exposure without rusting; great for use in marine and seawater settings.
Excellent corrosion resistance in broad range of industrial and chemical settings.
Good for use in hydrochloric acid; great for use against pitting & crevice corrosion in chlorides.
Excellent for use against chloride stress corrosion cracking.
Not to be used in phosphoric or nitric acid.
Max operating temperature of ~1000°F.
Can be cut, formed, and welded.

Features:



Excellent corrosion resistance in a wide range of acidic & alkaline environments
Especially suitable for reducing conditions
Good ductility & thermal conductivity
Good for sea water applications



Applications:



Monel 400 wire cloth is principally used in aerospace, chemical, brackish water, seawater, and power generation applications given its superior corrosion resistance properties. Additional industries and applications which commonly use Alloy 400 wire cloth include:

SUBMIT RFQ
Boiling
Commercial Cooking
Desalination
Dyeing
Electrical Components



Chemical Composition



Chemical Composition
Monel Alloy C, ≤ Si, ≤ Mn, ≤ S, ≤ Fe, ≤ Ni, ≥ Cu
400 UNS N04400 0.3 0.5 2 0.024 2.5 63 28.0-34.0

Shape

Sizes
 Round Wire 0.10 – 5 mm dia.
　 Shaped Wire Upto 45 mm2 area
　 Flat Wire Thinnest 0.15 mm
　 　 Widest 12.00 mm

Specs:

Diameter (mm) Tolerance (mm)
0.020-0.049 +0.002, -0.001
0.050-0.074 ±0.002
0.075-0.089 ±0.002
0.090-0.109 +0.003, -0.002
0.110-0.169 ±0.003
0.170-0.184 ±0.004
0.185-0.199 ±0.004
0.200-0.299 ±0.005
0.300-0.310 ±0.006
0.320-0.499 ±0.006
0.500-0.599 ±0.006
0.600-0.799 ±0.008
0.800-0.999 ±0.008
1.00-1.20 ±0.009
1.20-1.40 ±0.009
1.40-1.60 ±0.010
1.60-1.80 ±0.010
1.80-2.00 ±0.010
2.00-2.50 ±0.012
2.50-3.00 ±0.015
3.00-4.00 ±0.020
4.00-5.00 ±0.020





Corrosion Resistance Monel 400 Wire For Sea Water Applications 0

Corrosion Resistance Monel 400 Wire For Sea Water Applications 1
