Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength

  • Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength
  • Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength
  • Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength
  • Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 20 days
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Relatively Low Cost And High Strength Material Material Low Carbon Steel , Plain Steel, Mild Steel
Standard ASTM Type Welded
Hole Shape Square Hole Or Slot Hole Clear Opening 1/4" To 8"
Wire Diameter 0.063" To 3/8″ Panel Size Custom Sizes & 4′ X 8′ Panels Available
Roll Size 36" 48" 60" Width 100' Length Application Used Across A Wide Array Of Various Industries And Applications Due To Its Relatively Low Cost And High Strength.
Highlight

low carbon steel welded wire mesh

,

8" opening steel welded wire mesh

,

1/4" opening welded steel mesh
Leave a Message
Product Description

Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening Low Cost And High Strength



Welded Wire Mesh Introduction:



Low carbon steel wire mesh is the most common plain steel alloy used in manufacturing industrial wire cloth screens due to its tensile strength and high impact resistance. Primarily comprised of iron, low carbon grades 1005, 1006, and 1008 are the most frequently used, and contain small percentages of carbon (0.0-0.1%), manganese (0.0-0.5% – which increases its strength), phosphorous (0.0-0.04%), and sulfur (0.0-0.05%). Low abrasion resistance and low corrosion resistance may limit usage in certain applications, however a wide variety of special protective coatings may be applied to improve resistance. Galvanizing (before or after) is the most economical way to protect against corrosion. Alternatively, a protective tin coating is often used on mud grade screens (tinned mill). In addition, steel wire cloth can be protected with epoxy coatings, PVC/ inyl coatings, and our electrostatic application of powder coating. Some characteristics of low carbon steel wire cloth which dictate its wide use are:

Low carbon plain steel alloy.
Relatively low cost and high strength material.
Magnetic in all conditions.
Not corrosion resistant; rusts in most atmospheric environments.
Protective coatings can be applied to improve resistance.
Can be cut, formed, and welded.



Specifications:



Opening Size Wire Diameter
Inch mm SWG mm
1/4" × 1/4" 6.4 mm × 6.4 mm 22# - 24# 0.6 mm - 0.7 mm
3/8" × 3/8" 10.6 mm × 10.6 mm 19# - 22# 0.7 mm - 1.0 mm
1/2" × 1/2" 12.7 mm × 12.7 mm 16# - 23# 0.6 mm - 1.6 mm
5/8" × 5/8" 16 mm × 16 mm 18# - 21# 0.8 mm - 1.2 mm
3/4" × 3/4" 19.1 mm × 19.1 mm 16# - 21# 0.8 mm - 1.6 mm
1" × 1/2" 25.4 mm × 12.7 mm 16# - 20# 0.9 mm - 1.6 mm
1" × 1" 25.4 mm × 25.4 mm 14# - 21# 0.8 mm - 1.2 mm
1 1/2" × 1 1/2" 38 mm × 38 mm 14# - 19# 1.0 mm - 2.0 mm
1" × 2" 25.4 mm × 50.8 mm 14# - 16# 1.6 mm - 2.0 mm
2" × 2" 50.8 mm × 50.8 mm 12# - 16# 1.6 mm - 2.6 mm
2" × 3" 50 mm × 75 mm 13# - 16# 1.6 mm - 2.3 mm
3" × 3" 75 mm × 75 mm 12# - 16# 1.6 mm - 2.6 mm
2" × 4" 50 mm × 100 mm 13# - 14# 2.0 mm - 2.3 mm
4" × 4" 100 mm × 100 mm 13# - 14# 2.0 mm - 2.3 mm
8" × 8" 200 mm × 200 mm 13# - 14# 2.0 mm - 2.3 mm

Other sizes as your special request.



Material: Stainless Steel 304 or 316.



Features:



High tensile strength steel wire can prevent poultry from biting.
Hot dipped galvanized surface make hardware cloth excellent corrosion and rust resistance.
Solid structure can defend predators from attacking poultry.
Extended outside or buried underground design can keep predators out and poultry in.
Lightweight is easy to install and uninstall.
e. Hardware cloth has smooth surface, which there is no sharp edges may hurt poultry.
Used combined with welded wire mesh panel or chain link fence panel to improve the ety coefficient and protect poultry and animals.



Applicatioins:



Agricultural
Architectural & Artistic
Building & Construction
Cabinetry & Furniture
Cages & Enclosures
Fan Guards
Filtration & Particle Separation Disks
Fireplace Screen
Fuel Industries
Heat Treatment
Hydraulic Applications
Railing & Guardrail Infill Panels
Mining & Quarrying
Oil Strainers
ety Fencing & Machine Guards
Security & Prison
Window Guards
Wine Lockers







Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength 0



Packing:



in waterproof paper and film, then in pallets. Custom packing available at request.



Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength 1



Low Carbon Steel Welded Wire Mesh 1/4" To 8" Opening High Strength 2
