Weaving Twill Stainless Steel Dutch Wire Mesh Wear Resisting 30m X 2.0m
Place of Origin | Anping of China |
---|---|
Brand Name | QIANPU |
Certification | ISO |
Minimum Order Quantity | 1 roll |
Price | Negotiable according to quantity of order |
Packaging Details | 1. inside use carton pipe for support+wire mesh layer+water proof paper 2. outside use plastic wooden bags+wooden case/carton pipes/wooden pallets. 3. also we can as per your requirements. |
Supply Ability | 3000 rolls per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xFeatures | Wear-resisting, Heat-resisting, Acid-resisting And Corrosion Resisting. | Product Name | Stainless Steel Dutch Wire Mesh |
---|---|---|---|
Material | Stainless Steel 304 316 | Cert | ISO9001 |
Max Counts | 325 X 2300 | Width | 0.1 To 2.0m |
Length | 30m Or Customized | Color | Silver |
Weaving Pattern | Plain Dutch, Twill Dutch, Reverse Dutch | Application | Filtering |
Highlight | twill stainless steel dutch wire mesh,30m x 2.0m stainless steel dutch wire mesh,ss316 twill dutch weave wire mesh |
Stainless Steel Wire Mesh Dutch Weaving Plain Dutch Twill Dutch Reverse Dutch
Introduction:
Wire mesh filter cloth mainly refers to wire mesh products made with Dutch woven patterns. Our factory is an expert in woven wire mesh, especially custom and special type wire mesh filter cloth Dutch woven. Dutch Woven Wire Cloth can be further divided into mainly four types according to weaving patterns:
Wire Mesh Filter Cloth Dutch Plain Woven.
Wire Mesh Filter Cloth Dutch Twill Woven.
Wire Mesh Filter Cloth Reverse Dutch Woven.
Wire Mesh Filter Cloth Five-Heddle Woven.
Dutch Woven Wire Mesh Filter Cloth mainly refers to wire cloth made of stainless steel wire: Stainless Steel Wire Mesh (Cloth),SUS302, 304, 304L, 316, 316L. It can also be supplied in other metals including brass, copper and other alloy materials.
Wire Materials:
SUS302, 304, 316, 304L, 316L.
Characteristics:
Dutch Woven Wire Mesh Filter Cloth Property: This kind of woven wire mesh is wear-resisting, heat-resisting, acid-resisting and corrosion resisting.
Weaving Patterns:
Plain dutch, twill duth, reverse dutch, five heddle.
Packing:
stainless steel mesh made in small rolls,outside wooden cases.
Main Features:
Corrosion resistance.
Anti-acid and alkali.
Anti-high temperature.
Good filter performance.
Long using life
Applications:
Stainless Steel Dutch Woven Wire Cloth and other materials are utilized as filter fittings for chemical industry, medicine, petroleum, telecommunication, scientific research units and so on.
Details sheet:
Wire Mesh Filter Cloth Dutch Woven | ||||
Gauge No. | Mesh/Inch (Warp × Weft) | Wire Diameter | Reference Aperture | Weight/sq. |
(Warp × Weft) | (um) | (kg) | ||
32# | 8 × 62 | 0.63mm × 0.45mm | 300 | 5.42 |
40# | 10 × 79 | 0.50mm × 0.355mm | 250 | 3.16 |
48# | 12 × 64 | 0.58mm × 0.40mm | 280 | 2.9 |
55# | 14 × 88 | 0.40mm × 0.30mm | 180 | 2.54 |
76# | 19 × 140 | 0.315mm × 0.20mm | 140 | 1.88 |
80# | 20 ×300 | 0.35mm × 0.20mm | - | 3.6 |
95# | 24 × 110 | 0.355mm × 0.25mm | 120 | 2.45 |
100# | 25 × 140 | 0.28mm × 0.20mm | 100 | 1.95 |
120# | 30 × 150 | 0.25mm × 0.18mm | 80 | 1.68 |
140# | 35 × 175 | 0.224mm × 0.16mm | 71 | 1.52 |
160# | 40 × 200 | 0.20mm × 0.14mm | 60 | 1.4 |
180# | 45 × 250 | 0.16mm × 0.112mm | 56 | 1.09 |
200# | 50 × 250 | 0.14mm × 0.11mm | 53 | 1.04 |
220# | 55.5 × 280 | 0.14mm × 0.10mm | 50 | 0.92 |
240# | 65 × 330 | 0.11mm × 0.08mm | 36 | 0.71 |
280#(1) | 70 × 350 | 0.11mm × 0.08mm | 35 | 0.72 |
280#(2) | 70 × 385 | 0.11mm × 0.07mm | 32 | 0.75 |
300# | 78 × 700 | 0.11mm × 0.08mm | 30 | 1.39 |
315#(1) | 80 × 400 | 0.10mm × 0.065mm | 40 | 0.62 |
315#(2) | 80 × 600 | 0.10mm × 0.06mm | - | - |
315#(3) | 80 × 800 | 0.15mm × 0.04mm | - | - |
320# | 81 × 780 | 0.10mm × 0.07mm | 30 | 1.22 |
354# | 90 × 550 | 0.12mm × 0.05 | - | - |
Roll width: 1-1.6m |
Wire Mesh Filter Cloth Dutch Woven | ||||
Gauge No. | Mesh/Inch (Warp × Weft) | Wire Diameter | Reference Aperture | Weight/sq. |
(Warp × Weft) | (um) | (kg) | ||
360# | 91 × 787 | 0.10mm × 0.10 | 25 | 1.24 |
400# | 101 × 900 | 0.10mm × 0.10 | 20 | 1.22 |
472# | 120 × 400 | 0.10mm × 0.10 | - | - |
500# | 127 × 1100 | 0.07mm × 0.07 | 17 | 0.81 |
630# | 160 × 1500 | 0.063mm × 0.063 | 15 | 0.62 |
650#(1) | 165 × 400 | 0.017mm × 0.017 | - | - |
650#(2) | 165 × 600 | 0.017mm × 0.017 | - | - |
650#(3) | 165 × 800 | 0.017mm × 0.017 | 25 | - |
650#(4) | 165 × 1100 | 0.017mm × 0.017 | - | - |
650#(5) | 165 × 1400 | 0.017mm × 0.017 | 16 | 0.76 |
685# | 174 × 700 | 0.063mm × 0.063 | 13 | 0.61 |
787#(1) | 200 × 600 | 0.071mm × 0.071 | - | - |
787#(2) | 200 × 800 | 0.071mm × 0.071 | - | - |
787#(3) | 200 × 1400 | 0.071mm × 0.071 | 12 | 0.8 |
795# | 202 × 1760 | 0.05mm × 0.05 | 10 | 0.6 |
850# | 216 × 1860 | 0.045mm × 0.045 | 9 | - |
1000# | 254 × 2000 | 0.04mm × 0.04 | 8 | 0.5 |
1125# | 285 × 2235 | 0.036mm × 0.036 | 7 | - |
1228# | 312 × 2100 | 0.035mm × 0.035 | - | - |
1250# | 318 × 2235 | 0.036mm × 0.036 | - | - |
1280# | 325 × 2300 | 0.035mm × 0.035 | 5 | 0.45 |
Roll width: 1-1.6m |
Delivery Time
We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material. We'll check with our production department for the non-stock items to offer you the exact delivery time and producing schedule.
Mutual Benefit
If the products of our distributors are unmarketable due to the influence by market factors,we will seek customers in the same market or near market who are in need of the products to help the distributors to handle unsalable products.
Our other products
Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.
We are located in wire mesh industrial base Anping city,Hebei province in China.
Our product range is as below,
Stainless steel woven wire mesh
Welded wire mesh
Crimped wire mesh
Hexagonal wire mesh
Knitted wire mesh
Wire mesh filter
Window screen
It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.
In order to make an offer,please provide us below wire mesh specification information.
Material
Wire diameter
Mesh size
Wire mesh length
Wire mesh width
If it is possible,please also provide us weight per roll that you required.
