Crimped Facade Cladding Decorative Woven Metal Mesh Black

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50m length
Price Negotiable
Packaging Details Warpped with plastic film, then in wooden case.
Delivery Time 2weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Features Robust Specification And Good Stability, Design For Facade Product Name Wire Mesh Cladding With Special Crimps
Material Stainless Steel Wire, Copper Wire, Brass Wire, Phosphor Bronze Wire And Other Materials. Weaving Method Plain Crimped, Pre-crimped, Intermediate Crimped, Flat Top Crimped, Lock Crimped And Dutch Weave.
Wire Diameter 1.2mm - 4mm. Wire Pitch 1.5mm - 120mm.
Open Area 45% - 70% Application Used As The Facade Cladding And Building Cladding
High Light

crimped decorative woven metal mesh


facade cladding decorative woven metal mesh


facade cladding decorative black wire mesh

Leave a Message
Product Description

Crimped Wire Mesh Cladding With Durable Features Used As The Facade Cladding




Compared with cable metal mesh, crimped wire mesh is further amended. And it also can be used for building exterior facade mesh. The vertical cables are replaced by solid round wires, which offer more stiffness for the mesh. Due to its special crimps, this type of wire mesh becomes more robust and corrosion resistant. It is mainly made of stainless steel wire, copper wire, brass wire, phosphor bronze wire and other materials. Besides, each panel is fitted with a series of clevis screws and the U channel substructure at the top and the bottom. This provides the optimum tension for the building exterior facade. The result is a homogeneous facade without interruptions.


Its inherent stability and varying degrees of transparency make crimped wire building facade mesh become an incredible versatile mesh suitable for many interior and exterior applications. We can offer you various styles of crimped wire mesh for building facade.




Robust specification and good stability, design for facade.
High open area.
Anti-corrosion, and anti-rust.
Groups of wires create the vertical structure.
The strength of the utilized material makes it durable.
A high degree of transparency because of the special weave structure.




Crimped wire mesh is widely used as the facade cladding and building cladding in the high-class building constructions, the office buildings, parking garages and the shopping mall, etc.


For example, the crimped wire mesh facade for a car park, that can be used as a security screen and the same time enhances the optical appearance of the building. Especial at the night, with the effect of light and shadow, and its high transparency, the buildings can capture the eyes of passersby.




Triple Warp Weave Mesh-1
Material Stainless Steel Wire
Wire Diameter 1.6mm × 2.9mm
Aperture 50mm × 8mm
Open Area 65%


Triple Warp Weave Mesh-2
Material Stainless Steel Wire
Wire Diameter 3.15mm
Aperture 40mm×20mm
Open Area 60%


Triple Warp Weave Mesh-3
Material Stainless Steel Wire
Wire Diameter 3.15mm
Aperture 60mm×9mm
Open Area 59%


Triple Warp Weave Mesh-4
Material Copper Wire
Wire Diameter 2.5mm
Aperture 45mm×9mm
Open Area 45%

Other Specifications according to your requirements.


Crimped Facade Cladding Decorative Woven Metal Mesh Black 0


Crimped wire mesh with 2mm weft wire.


Crimped wire mesh with three 2.45mm warp wire.


Crimped wire mesh with 2 warp wire.



Packing: Crimped wire mesh is packed in rolls or panels, wrapped in moisture-proof paper or plastic film, outside wooden cases.


Crimped Facade Cladding Decorative Woven Metal Mesh Black 4
