Corrosion Resistance 8mm Stainless Steel Expanded Metal Mesh Good Strength

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 10Rolls
Price Negotiable
Packaging Details Plastic out side then in pallet or wooden box.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Anti-rusting And Heat Resistance Product Name Stainless Steel Expanded Metal Mesh
Material Stainless Steel Surface Bright Silver
Pattern Raised Type, Flatterned Type Hole Diamond
Thickness 0.5 To 8mm Width Max 2200mm
Length Customized Application Typically Used As Machine Guards, Window / Vent Guards, Security Mesh
High Light

8mm stainless steel expanded metal mesh

,

anticorrosion stainless steel expanded metal mesh

,

corrosion resistance stainless expanded metal mesh

Leave a Message
Product Description

Stainless Steel Expanded Metal Mesh With Corrosion Resistance And Good Strength



Stainless Steel expanded Metal Mesh introduction:



Stainless steel expanded metal is made of stainless steel metal sheet, through die slitting and stretching to form uniform diamond shaped openings. In the manufacturing process, no material is lost, and it offers savings in weight, as well as free passage of light, liquid, sound and air. Stainless steel expanded metal is more rigid than an equal weight of solid steel plate or wire mesh, making it popular in architectural and commercial areas. It is worth mentioning that 18 gauge (0.05" thick) 304 stainless steel and 316 L stainless steel are materials that commonly used. But there is difference between them, so choose suitable material for your needs, and the following information will help you learn more about stainless steel expanded metal.



Materials of raised expanded metal sheet:


Raised expanded metal sheet can be made of steel expanded metal sheet, aluminum expanded metal sheet, stainless steel expanded metal sheet and other alloy sheet. Steel expanded metal sheet can be electric galvanized, hot-dipped galvanized or PVC coated. Galvanized expanded metal sheet can supply bright and chemical stabilized surface and the PVC coated expanded metal sheet can supply various colors to suit different environments and applications. Stainless steel expanded metal sheet supplies chemical and biological stabilization. Additional, the stainless steel expanded metal sheet is the most durable type.



Hole patterns of raised expanded metal sheet:

stainless steel 304, 316, 316 L.



Specifications:



Raised Expanded Metal
Mesh Pitch Mesh Pitch Strand Width(mm) Strand Thickness(mm)

Sheet Size

(mm)

Material Type
LW (mm) SW (mm)
3 1.9 0.6 0.4 500 x 1000 Mild Steel
5.84 3.5 0.79 0.6 1250 x 1250 Mild Steel
10.24 5.64 1.55 0.9 1250 x 1250 Mild Steel
19.05 7.43 1.7 0.9 1250 x 2500 Mild Steel
19.05 9.5 1.22 1.2 1250 x 1250 Mild Steel
25.4 12.7 1.27 1.2 1250 x 1250 Mild Steel
25.4 13.5 3 0.9 1250 x 2500 Mild Steel
28.58 9.52 1.98 1.2 1250 x 2500 Mild Steel
30.48 11.72 2.36 1.6 2440 x 1220 Mild Steel
30.48 11.72 1.98 1.6 2440 x 1220 Mild Steel
38.1 16.93 3.08 1.6 2440 x 1220 Mild Steel
38.1 16.48 2.25 1.6 2440 x 1220 Mild Steel
50.8 22.58 3.89 3 2440 x 1220 Mild Steel
50.8 22.58 3.12 3 2440 x 1220 Mild Steel & H D Galv
50.8 22.58 2.52 2.5 2440 x 1220 Mild Steel
50.8 22.58 3.05 1.6 2440 x 1220 Mild Steel
76.2 33.87 3.58 3 2440 x 1220 Mild Steel
85.73 40.64 3.18 3 2440 x 1220 Mild Steel
101.6 50.8 5.03 3 2440 x 1220 Mild Steel
101.6 50.8 3.35 3 2440 x 1220 Mild Steel
121.92 31.28 3.5 3 2440 x 1220 Mild Steel
5.84 3.5 0.79 0.6 1250 x 1250 Pre-Galv
5.84 3.5 0.79 0.6 1250 x 2500 Pre-Galv
10.24 5.64 0.79 0.6 1250 x 1250 Pre-Galv
10.24 5.8 2.45 1.5 750 x 1250 Pre-Galv
19.05 9.5 1.22 1.2 1250 x 1250 Pre-Galv
25.4 12.7 1.27 1.2 1250 x 1250 Pre-Galv
30 11.1 1.83 0.9 1250 x 700 Pre-Galv
50.8 23 2.5 0.6 1250 x 2440 Pre-Galv
5.84 3.5 0.79 0.5 1250 x 1250 Aluminium
5.84 3.5 0.79 0.5 1250 x 2500 Aluminium
5.84 3.5 0.79 0.5 1250 x 3000 Aluminium
10.24 5.64 1.17 1.2 1250 x 1250 Aluminium
10.24 5.64 1.55 0.9 1250 x 1250 Aluminium
10.24 5.64 1.55 0.9 1250 x 2500 Aluminium
19.05 12.7 1.1 1.2 1250 x 2500 Aluminium
19.05 7.43 1.7 0.9 1250 x 2500 Aluminium
19.05 9.5 1.22 1.2 1250 x 1250 Aluminium
25.4 11.67 1.27 1.2 1250 x 1250 Aluminium
30.48 11.72 2.36 1.2 1250 x 2500 Aluminium
50.8 22.58 3.12 3 2500 x 1250 Aluminium
5.84 3.39 0.8 0.5 1250 x 1250 Stainless 304
19.05 7.26 1.71 0.9 1000 x 2000 Stainless 304
38.1 16.48 1.91 1.2 2500 x 1250 Stainless 304
50.8 23.44 2.65 1.2 2500 x 1250 Stainless 304
30 10.5 1.5 0.5 2500 x 700 Stainless 304
50.8 22.5 1.6 0.6 1250 x 2440 Stainless 430



Features of raised expanded metal sheet:



Stainless steel 304 for anti-rusting and heat resistance.
Stainless steel 316 has more corrosion resistance.
Easy to be welded and cut for your ideal form.
Resistant to high temperature and food grade stainless steel especially designed for BBQ grill.
High mechanical strength for many applications that need large load bearing.



Applications of raised expanded metal sheet:



Stainless steel expanded metal is typically used as machine guards, window / vent guards, security mesh for bank or parking lot, architectural material and decorative mesh. 304 stainless steel is a commercial grade of stainless steel metal sheet and most widely used. Its applications include architectural areas, expanded metal chimney caps, vent or animal guards and concrete reinforcement. It is not recommended for uses in walkways, grills, or trailers for it's not strong enough.



Corrosion Resistance 8mm Stainless Steel Expanded Metal Mesh Good Strength 0

Corrosion Resistance 8mm Stainless Steel Expanded Metal Mesh Good Strength 1

Corrosion Resistance 8mm Stainless Steel Expanded Metal Mesh Good Strength 2

Packing:



Expanded metal should be packed firmly and securely.When packing, expanded metal appears in roll type and flat type



Corrosion Resistance 8mm Stainless Steel Expanded Metal Mesh Good Strength 3
