Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings

  • Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings
  • Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings
  • Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 10Rolls
Price Negotiable
Packaging Details Plastic out side then in pallet or wooden box.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features More Economic Product Name Steel Expanded Metal Diamond Shaped
Material Carbon Steel Surface Galvanized, Powder Coated, PVC Coated, Etc.
Pattern Flattened Type, Raised Type Hole Diamond
Thickness 0.5 To 8mm Shape Rolls Or Panels
Application Architectural Fencing, Security Screen, Etc
Highlight

diamond openings expanded metal filter mesh

,

0.8mm thick expanded metal filter mesh

,

0.8mm thick expanded metal mesh
Leave a Message
Product Description

Steel Expanded Metal Diamond Shaped Openings With Uniform Sizes With Low Cost



Steel Expanded Metal Mesh Introduction:



Steel expanded metal is produced from one steel plate or roll through simultaneously slitting and stretching, which forms a wide array of diamond shaped openings with uniform sizes. During the expanding process, the metal can be expanded up to ten times its original width, losing up to 80 % its weight per meter, and becomes more rigid. It is lighter, less expensive than a single metal sheet, and also allows for free flow of liquid, heat, air and sound, yet producing impenetrable barrier to larger solid objects (or persons). Compared with the traditional flat metal sheet, steel expanded metal has more notable advantages for its versatile applications. More and more new applications are found for it in the family, office, and other industrial, commercial fields.





Specifications:

Surface treatment: hot-dip galvanizing, anti-rust paint, powder coated, PVC coated, etc.
Thickness: 9 gauge to 20 gauge.
Available sheet sizes: 1' × 2', 1' × 4', 2' × 2', 2' ×4', 4' × 4', 4' × 8', 5' × 10', or made to size.



Flattened Expanded Metal
Mesh Aperture Mesh Aperture Strand Width Strand Thickness Sheet Size LWD x SWD Material Type
LW (mm) SW (mm)
3.81 2.03 0.79 0.6 1250 x 1250 Mild Steel
6.85 3.56 1.3 0.9 1250 x 2500 Mild Steel
9.5 5 1.3 0.9 1250 x 2500 Mild Steel
14.22 4.8 1.85 0.9 1250 x 2500 Mild Steel
23.11 5.84 3.2 1.52 2440 x 1220 Mild Steel
24.38 7.11 2.39 1.14 2440 x 1220 Mild Steel
24.38 7.87 2.06 1.47 2440 x 1220 Mild Steel
24.38 7.62 2.08 1.14 1250 x 2500 Mild Steel
32.77 10.92 3.18 1.5 2440 x 1220 Mild Steel
33.53 12.45 2.31 1.14 1250 x 2550 Mild Steel
33.53 12.45 2.31 1.14 2440 x 1220 Mild Steel
42.93 14.22 4.6 2.69 2440 x 1220 Mild Steel & H D Galv
42.93 14.22 4.6 2.69 1250 x 2500 Mild Steel & H D Galv
39.12 18.29 4.72 2.74 1220 x 2500 Mild Steel
43.43 18.03 2.31 1.14 1250 x 2500 Mild Steel & Pre-Galv
43.18 17.27 3.23 1.45 2440 x 1220 Mild Steel
42.93 17 6 3.7 1220 x 2440 Mild Steel
77.47 27.18 6.53 2.9 2440 x 1220 Mild Steel
3.5 2.05 0.79 0.56 1250 x 1250 Pre-Galv
5 3.45 1.3 0.7 1250 x 2500 Pre-Galv
6 4 0.8 0.6 1250 x 1250 Pre-Galv
35.05 12.45 2.31 1.14 1250 x 2500 Pre-Galv
6.86 3.56 1.27 0.9 1250 x 2500 Aluminum
13.97 4.83 1.8 0.9 1250 x 2500 Aluminum
24.1 7.11 2.39 1.14 1250 x 2440 Aluminum
35.05 11.94 2.34 1.14 1250 x 2440 Aluminum
40.64 17.78 4 2.9 1250 x 2500 Aluminum
43.18 17.78 2.34 1.12 1250 x 2000 Aluminum
3.5 2.05 0.75 0.5 1250 x 1625 Stainless 430
11.7 8.5 1.5 1.5 1000 x 2000 Stainless 304
14.22 4.3 1.83 0.9 1000 x 2000 Stainless 304
14.22 4.3 1.83 0.9 1250 x 1830 Stainless 316
21 6 2.1 1.2 1250 x 2500 Stainless 304
21 9 3 1.5 1250 x 2500 Stainless 304



Shearing methods



Expanded metal shearing methods include four ways from two directions. They give you an instruction when ordering expanded metal.

End bond shearing: One end is cut on the bond parallel to the SWD, the other end usually has open diamonds.
End random shearing: The shearing direction is parallel to the SWD. The end random cut normally leaves open diamonds at the ends.
Side bond shearing: Side bond cut is made along the length of the metal sheet on the center line of the bond over the specific width.
Side random shearing: Side random shearing is cut that is parallel to the LWD dimension of the metal sheet, leaving opening diamonds.



Surface Treatment: hot-dipped, electrol galvanized, pvc-coated.





Flattened Expanded Metal is formed by flattening process based on standard expanded metal. Its strand width and bond are in the same horizontal plane with plate surface. Compared with standard expanded metal,the plate thickness will be thinner and opening will be larger.

Flattened Expanded Metal With Material Stainless Steel 304, 316, etc

Flattened Expanded Metal With Material Stainless Steel 304, 316, etc

Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings 2



Features:



One piece and single unit construction.
Less weight and more economic than regular metal sheet.
Extensive range of materials to suit any application.
It is rigid for protective uses, while providing decorative effect.
High quality for durable use.
The most economical option among all metal materials.
Easy to install.



Applications of flattened expanded metal sheet:



The applications are as endless as the benefits gained, so steel expanded metal applications are not limited to the following lists.

Interior partition and barrier.
Architectural fencing.
Security screen.
Ceiling tile.
Building cladding.
Dust bin.
Garden bench and furniture.
Walkway and stair tread.
Display stand.
Vent guard and chimney cover.
Car grille.
Grain drying rack.
Air filter and air intake screen.
Seedbed in flower farming.





Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings 3



Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings 4

Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings 5



Packing:



Expanded metal should be packed firmly and securely.When packing, expanded metal appears in roll type and flat type



Steel 0.8mm Thick Expanded Metal Filter Mesh Diamond Shaped Openings 6
