Material Mild Perforated Steel Mesh High Strength 1m Width

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 10Rolls or Panels
Price Negotiable
Packaging Details Warpped with plastic film, then in wooden case or pallets.
Delivery Time a week
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Features High Strength And Cost Effective Material Product Name Mild Steel Perforated Mesh
Material Mild Steel Hole Shape Round, Slot, Square, Hexagnoal, Etc
Punched Perforated Thickness 0.5mm To 8.0mm
Hole Pattern 90°, 45°, 60° Width 1m, 1.22m, 1.5m To 4m
Length 15m, 30m To 60m Application Vibrating Screen, Mining Industry, Etc
High Light

material mild perforated steel mesh


high strength perforated steel mesh


1m width perforated metal mesh

Leave a Message
Product Description

Cost Effective Material Mild Steel Perforated Mesh High Strength Perforated Metal Mesh


Mild Steel Perforated Mesh Introduction:


Carbon steel is divided into high carbon steel, medium carbon steel and low-carbon steel according to different carbon content. The higher the carbon content, the higher the hardness and strength of carbon steel, while the lower the plasticity. Our carbon steel perforated screen has low price and high strength. It is widely used in construction and industry.


Carbon steel has two treatment types: hot rolling and cold rolling. Hot rolling is the first process of steel molding. Steel becomes hard and brittle after cold rolling. After degrease and annealing, the steel will recover its toughness.

Mild steel is not very corrosion resistant. Generally, we can provide galvanization, sprayed painting, PVC coating and other surface treatments to protect it from corrosion.



High carbon steel. 0.8% to 2.0% carbon content. It has high strength but poor toughness. We usually use it to make vibrating screen and mine sieving mesh.
Medium carbon steel. 0.3% to 0.8% carbon content. It is used to manufacture stainless steel.
Low carbon steel. 0.05% to 0.30% carbon content. It has the shortest tempering time. It is soft, stamping resistant with good ductility.


Parts of Specifications:


Hole Diameter Staggered Centers Sheet Thickness Open Area
0.045" 1.14mm 0.66" 0.033-0.039" 0.84-0.99mm 37%
1/16" 1.59mm 3/32" 0.027-0.033" 0.68-0.84mm 41%
1/16" 1.59mm 1/8" 0.027-0.066" 0.68-1.68mm 23%
5/64" 1.98mm 1/8" 0.027-0.053" 0.68-1.35mm 35%
0.081" 2.06mm 1/8" 0.053-0.066" 1.35-1.68mm 38%
3/32" 2.38mm 5/32" 0.053*0.066" 1.35-1.68mm 33%
1/8" 3.17mm 3/16" 0.027-0.127" 0.68-3.23mm 40%
5/32" 3.97mm 3/16" 0.027-0.056" 0.68-1.68mm 63%
3/16" 4.76mm 1/4" 0.027-0.127" 0.68-3.23mm 50%
1/4" 6.35mm 3/8" 0.033-0.011",0.25" 0.84-2.82mm,6.35mm 40%
3/8" 9.52mm 1/2" 0.053-0.082",3/16" 1.35-2.08mm,4.76mm 51%
3/8" 9.52mm 9/16" 0.059",0.119" 1.5mm,3.02mm 40%
1/2" 12.7mm 11/16" 0.033-0.127",3/16" 0.84-3.23mm,4.76mm 48%
1/4" Hex 6.35mm 0.285" 0.027-0.033" 0.68-0.84mm 76%
3/8" Sq 9.52mm Cane" 0.053-0.066" 1.35-1.68mm 51%

Other Specifications according to your requirements.



Energy production
Mining industry
Cement production
Vibrating Screen
Wind Dust Fence
Noise Barrier


Hole Patterns including:

Round; Rectangular hole; Square; Triangle; Diamond; Slotted Hole; Hexagonal; Cross; Slotted; and other patterns according to your drawings or application requirement.


Material Mild Perforated Steel Mesh High Strength 1m Width 0


Material Mild Perforated Steel Mesh High Strength 1m Width 1

Material Mild Perforated Steel Mesh High Strength 1m Width 2




Energy production.
Mining industry.
Steel production industry.
Waste processing.
Lorries, buses and train.
Cement production.
Automotive & Transport.



Material Mild Perforated Steel Mesh High Strength 1m Width 3

Material Mild Perforated Steel Mesh High Strength 1m Width 4


Our Perforated Metal Mesh List:


Round hole perforated sheet
Square hole perforated sheet
Slot hole perforated sheet
Decorative Perforated Sheet
Embossed sheet
Perforated steel sheet
Perforated stainless steel sheet
Perforated aluminum sheet
perforated copper or brass sheet
Etched plates
Perforated metal noise barrier
Perforated filter form SS, carbon steel, aluminum, or copper sheet
Perforated tube
Perforated sunshade panel
Perforated kinetic facade
Anti-skid stair steps
Hexagonal hole perforated metal
Louver hole perforated metal
Raised Perforated Metal
Nickel perforated metal
Galvanized perforated metal
Carbon steel perforated metal
Perforated metal for filter
Perforated Metal for facade
