Reverse Ss 304 Dutch Weave Wire Mesh Flexible With Excellent Filtration

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 5 Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case.
Delivery Time 40 days
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Mechanically Strong With A High Throughput And It Performs Particularly Well In High Pressure Product Name Stainless Steel Reverse Dutch Weave Wire Mesh
Material 304, 304L, 316, 316L, Other Metal Material Can Be Customized. Standard AISI, DIN
Surface Bright Silver Weaving Type Reverse Dutch Weave
General Mesh 72×15, 132×14, 132×18, 152×30, 250×40, Etc. Roll Width 67mm, 95mm, 97mm, 127mm, 133mm, 150mm, 157mm,300mm, 400mm, Max Width 50cm
Roll Length 120', 60', Or Cutsomed Application Widely Used As A Filters Media In Plastic Wire Drawing Machine, Stretch Film Machine, Coating Machine Filters, Plastic Recycling Filter, Polymer Melt Filtration
High Light

ss 304 dutch weave wire mesh

,

excellent filtration dutch weave wire mesh

Leave a Message
Product Description

Stainless Steel Reverse Dutch Weave Flexible With Excellent Filtration Dutch Wire Mesh

Reverse Dutch Weave Wire Mesh



In Reverse Dutch Weave Wire Mesh, thin warp wires are positioned close to each other and the thicker weft wire is woven in at a defined distance. The resulting higher strength in the warp direction makes popular for use as a filter belt.

Comparing with the normal plain Dutch weave mesh, the coarser wire in the weft direction and the finer wire in the warp direction, this weave can supply better filtration rate.

Our stainless steel reverse Dutch belts are made of high quality, high strength stainless steel wires.

Material: Stainless steel wire 304, 304L, 316, 316L, other metal material can be customized.
Weave type: Reverse Plain Dutch Weave(RPD) and Twilled Reverse Dutch Weave(TRD)
General Mesh:72×15, 132×14, 132×18, 152×30, 250×40, etc.
Roll width: 67mm, 95mm, 97mm, 127mm, 133mm, 150mm, 157mm,300mm, 400mm, Max width 50cm
Roll length: 120' or 60' (Can be customized)



Specifications



General Mesh of Reverse Dutch Weave

Weave of Type

Mesh/Inch

Wire Diameter

Nominal Micron

mm

μm

TRD

48 ×10

0.50 × 0.50

400

TRD

72 × 15

0.50 × 0.50

300

TRD

132 ×14

0.35 × 0.45

200

TRD

132 × 18

0.35 × 0.44

180

TRD

152 × 24

0.27 × 0.40

160

TRD

152 × 30

0.27 × 0.30

130

RPD

250 ×40

0.15 × 0.25

90

RPD

260 × 40

0.15 × 0.27

125

RPD

280 × 70

0.089 × 0.21

45

RPD

325 × 39

0.13 × 0.24

55

RPD

600 ×125

0.043 × 0.12

20

RPD

720 × 150

0.035 × 0.107

15

Other size according to your requirements.





Weave Type:

Reverse Plain Dutch Weave

Reverse Ss 304 Dutch Weave Wire Mesh Flexible With Excellent Filtration 0



Reverse Twilled Dutch Weave

Reverse Ss 304 Dutch Weave Wire Mesh Flexible With Excellent Filtration 1




Features:



The Stainless Steel Reverse Dutch Belts cloth is mechanically strong with a high throughput and it performs particularly well in high pressure vertical and horizontal filter leaf applications where backwashing and filter cake removal are important.



Smooth surface, continuous net, no deformations
High temperature resistance
corrosion resistance
Flexible with excellent filtration performance
High hardness, good load strength



Applications:



Widely used as a filters media in Plastic wire drawing machine, stretch film machine, coating machine filters, plastic recycling filter, polymer melt filtration
Filter for plastic, rubber, oil industry
Rubbed edges after slitting to help with tracking for Auto-Screen changers.
High tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry.
Auto Plastic Extruder Reverse Dutch Weave Mesh Belt
Reverse plain Dutch weave mesh is also used in applications requiring specific acoustic properties, mechanical robustness and high throughput for filtration.



Reverse Ss 304 Dutch Weave Wire Mesh Flexible With Excellent Filtration 2

Packing:



Stainless steel wire mesh is packed in rolls,winding on a paper tube,wrapped in moisture-proof paper or plastic film, outside wooden cases or wooden pallet.





Robusta Wire Mesh Excellent Filtration Stainless Steel Dutch Wire Mesh 3



Questions: What specs are needed to quote?

Answer: Material, woven type, aperture or mesh counts, wire diameter, roll width x roll length and number of rolls.

Reverse Dutch Weave Belts, Stainless steels in stock
Weave of Type Mesh/Inch Wire Diameter Nominal Micron
mm μm
TRD 48 ×10 0.50 × 0.50 400
TRD 72 × 15 0.50 × 0.50 300
TRD 132 ×14 0.35 × 0.45 200
TRD 132 × 18 0.35 × 0.44 180
TRD 152 × 24 0.27 × 0.40 160
TRD 152 × 30 0.27 × 0.30 130
RPD 250 ×40 0.15 × 0.25 90
RPD 260 × 40 0.15 × 0.27 125
RPD 280 × 70 0.089 × 0.21 45
RPD 325 × 39 0.13 × 0.24 55
RPD 600 ×125 0.043 × 0.12 20
RPD 720 × 150 0.035 × 0.107 15
