High Temperature AISI 1mm To 3mm Wire Conveyor Belt Stainless Steel

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xFeatures | Smooth Conveying Surface. | Product Name | Perforated Plate Conveyor Belt |
---|---|---|---|
Material | Stainless Steel Round Wire Or Flat Wire | Standard | AISI, DIN, SUS, Etc |
Diameter Of Spiral Wire | 1mm To 3mm | Pitch Of Spiral Wire | 6mm To 20mm |
Diameter Of Cross Rod | 1mm To 4mm | Pitch Of Cross Rod | 6mm To 20mm |
Width | As Your Request | Application | Food Processing Industries Such As Cooking, Baking And Cleaning, Etc. |
Highlight | 3mm Wire Conveyor Belt,1mm Wire Conveyor Belt,Stainless Steel mesh conveyor belt |
Stable Structure Round Wire and Flat Wire Stainless Steel Spiral Conveyor Belt
Stainless Steel Spiral Conveyor Belt Introduction:
Stainless Steel Spiral Conveyor Belt are used through a variety of industries from food processing to heat treatment. Wire belt patterns include: Balance, Compound, Duplex, Chain Driven, Baking Bands, etc. Spiral wire belting makes the premier material for the major conveyor applications.
Wire conveyor belt is made of various metals which will with stand both atmospheric and chemical corrosion, or of any alloy which will resist heat treating furnace temperatures. To eliminate any danger of product contamination, stainless steel wire belts are recommended.
Types of specifications:
Types | Pitch | Belt width | Wire diameter | Cross rod diameter | U-shape link height | U-shaped link width |
Standard U-shape link | 3/4" | 2.2m | 2mm | 5mm | 11mm | 28mm |
Standard U-shape link | 1" | 1.7m - 2.2m | 2mm | 5mm | 11mm | 29mm |
Heavy duty U-shape link | 1" | 2.2m | 3mm | 5mm | 11mm | 36mm |
Heavy duty U-shape link | 1" | 1.7m - 2.2m | 3mm | 5mm | 11mm | 41mm |
Heavy duty with double reinforced plate | 1" | 1.7m - 2.2m | 3mm | 5mm | 11mm | 41mm |
Types of Belt Ends:
Features of stainless steel chain conveyor belt mesh :
Stable design for smoothly, dependably and gentle movements.
Money saving by securing the quality of products and reducing waste.
Close-structure structure and ideal for high tensile load.
Suitable for radius system, spiral, curved or straight conveyors.
Wide temperature range from -196°C to +275°C.
Complying with FDA standards.
Industries served:
Food Industry - Conveying, washing, blanching, drying, frying, freezing, baking, cooling, wrapping, packing, canning, bottling etc.
Heat Treatment - Brazing, bluing, hardening, washing, degreasing, pickling, sintering, quenching, rinsing, tempering, drawing, enameling, etc.
Ceramics and Glass Industries - Annealing, decorating, sanding etc.
Specifications according to your requirements.
Applications:
Stable design for smoothly, dependably and gentle movements.
Money saving by securing the quality of products and reducing waste.
Close-structure structure and ideal for high tensile load.
Suitable for radius system, spiral, curved or straight conveyors.
Wide temperature range from -196°C to +275°C.
Complying with FDA standards.
Image shows: used for hot air withering conveyor for tea leaves
Packing:
Warpped with water-proof plastic material, then in wooden box.
Our wire mesh conveyor belts product list:
Flat Wire Conveyor Belt
Rod Network Belt
Rod Conveyor Belt
Eye Flex Conveyor Belt
Balanced Weave Conveyor Belt
Compound Weave Conveyor Belt
Universal Weave Conveyor Belt
Conventional Weave Conveyor Belt
Flat Top Chains
Metal Chain Plate Conveyor Belt
Radius Conveyor Belt
Ladder Conveyor Belt
Flat Rolled Baking Belt
Oven Mesh Belt
Flat Flex Conveyor Belt
Flexible Rod Conveyor Belt
Perforated Plate Conveyor Belt
Chain Link Conveyor Belt
Conveyor Belt Accessory: Roller Chain Sprocket, Roller Chains, etc
