Black Powder Coated Stainless Steel Security Screens DIN
| Place of Origin | Anping of China |
|---|---|
| Brand Name | QIANPU |
| Certification | ISO |
| Minimum Order Quantity | 150 square meters |
| Price | 15 to 80 us dollar/square meter |
| Packaging Details | Inside 1 roll seperately in waterproof paper then packed it inside of wooden carton |
| Delivery Time | 2 weeks |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 30 0000 square meters per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Stainless Steel Security Screen Mesh | Security Screen Material | Stainless Steel 304 |
|---|---|---|---|
| Standard | AISI, DIN | Mesh | 10*10 14*14 16*16 18*18 22*22 24*24 |
| Treatment | Powder Coated, Epoxy, Etc | Color | Black, Etc |
| Width | 1m, 1.2m, 1.5m Or Customized | Length | Standard 30 Meters |
| Feature | Soundproof, Anti-Theft, Airproof, Insect-proof, Dust-proof, Invisible, Decoration | Application | Securty Screen For Window And Doors |
| High Light | din Powder Coated Stainless Steel Security Screens,Black security screens stainless steel mesh,DIN stainless steel wire screen |
||
Product Description
SS304 Customized Black Powder Coated Stainless Steel Security Screen Mesh
ss304 security screen intorduction:
304 grade stainless steel mesh made from 0.9 mm thick wire with 11 mesh pattern is the best security mesh screen available on the market for secure doors, windows and outdoor areas from intruders and flies, mosquitoes and other pests.
The 0.9 mm thick 304 security screen ensures that it is harder to cut through or penetrate. If you kick at the mesh repeatedly, you can not break through it, but you will injure yourself. This heavy duty 304 mesh with black power coated has more anti-corrosion function.
Apart from high strength and anti-corrosion, the black 304 stainless steel mesh has other two import benefit. First, if you in the room, it gives you a clear and unobstructed view of the outdoor, but viewers can not peep your privacy from outside. Second, as a security screen mesh it allows the free flow and circulation of fresh air for your comfort.
Specifications:
Materials: GB 304 stainless steel.
Wire diameter: 0.90 mm.
Model (mesh count): 10 mesh, 11 mesh, 12 mesh, 14 mesh, 18 mesh.
Width: 0.8–1.5 m.
Length: 2.4 m / 31.5 m.
Color: black, gray, silver, light gray.
Service life: guarantee 10 years.
Packing:
5 pieces in one carton box, then 10 carton boxes in one wooden case or 25/50 pieces per wooden case.
In fumigation-free wooden cases.
Material Chemical Composition:
| Chemical composition of stainless steel wire: | ||||||||
| Grade | Chemical Composition(%) | |||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | |
| 304 | =0.08 | =1.00 | =2.00 | =0.045 | =0.030 | 8.00~10.50 | 18.00~20.00 | - |
| 304H | >0.08 | =1.00 | =2.00 | =0.045 | =0.030 | 8.00~10.50 | 18.00~20.00 | - |
| 304L | =0.030 | =1.00 | =2.00 | =0.045 | =0.030 | 9.00~13.50 | 18.00~20.00 | - |
| 316 | =0.045 | =1.00 | =2.00 | =0.045 | =0.030 | 10.00~14.00 | 10.00~18.00 | 2.00~3.00 |
| 316L | =0.030 | =1.00 | =2.00 | =0.045 | =0.030 | 12.00~15.00 | 16.00~18.00 | 2.00~3.00 |
| 430 | =0.12 | =0.75 | =1.00 | =0.040 | =0.030 | =0.60 | 16.00~18.00 | - |
| 430A | =0.06 | =0.50 | =0.50 | =0.030 | =0.50 | =0.25 | 14.00~17.00 | - |
Specification of stainless steel wire mesh:
| Material | Mesh per inch | Wire Dia (mm) | Wire Dia (inch) | Open Area |
| AISI 316 or 304 | 10 x 10 | 0.9mm | 0.035" | 41.7 |
| AISI 316 or 304 | 10 x 10 | 1.2mm | 0.028" | 27.8 |
| AISI 316 or 304 | 10 x 10 | 0.8mm | 0.032" | 46.9 |
| AISI 316 or 304 | 10 x 10 | 1.15mm | 0.045" | 29.9 |
| AISI 316 or 304 | 11 x 11 | 0.8mm | 0.032" | 42.5 |
| AISI 316 or 304 | 11 x 11 | 0.7mm | 0.027" | 48.3 |
| AISI 316 or 304 | 12 x 12 | 0.7mm | 0.027" | 44.8 |
| AISI 316 or 304 | 12 x 12 | 0.58mm | 0.023" | 52.8 |
Other specifications can also be customized
Features:
Excellent resistance to corrosion and impact.
Quality meets the demands of GB/T 1220–2007 Stainless Steel Rod standard grade.
Good privacy protection and aesthetic effect.
Easy to install with flat and straight surface.
Good air circulation & high quality daylighting.
Packaging & Payment term:
Package:Water proof inside and then wood box out side.
Payment term:T/T 30% advance payment
Delivery Time:25days
Characteristic of stainless steel window screen:
(1) shape: like iron plate -- hard, e ,Strong resistance to protect hitting
(2) Good light transmission Watching high-definition from the inside, from the outside looking blurred
(3) Prevent mosquitoes, theft
(4) Good stability, rust prevention, alkaline prevent, no afraid of damp and sun
(5) Ease of care: easy to clean dirty with a vacuum cleaner, absorbent sponge or brush
Application of stainless steel window screen:
Security screen is an ideal choice for windows and doors, as a heavy-duty shield, which can effectively protect your home and office. Besides it is also suitable for government departments, commercial office buildings, premium villas and residential areas. This advanced product is often applied to prevent intruders, burglars, storm and other destruction.
(1) Organization units, security progression higher unit - Bulletproof
(2) Office buildings, villas, residential - theft
(3) Mosquitoes are more mountainous, wild, suburban - anti-mosquito
(4) Unified management, residents or business area - beautiful
(5) Wet or dry city - corrosion and exposure.
(2) Office buildings, villas, residential - theft
(3) Mosquitoes are more mountainous, wild, suburban - anti-mosquito
(4) Unified management, residents or business area - beautiful
(5) Wet or dry city - corrosion and exposure.
