Stainless Steel 304 And 316 SS Welded Wire Mesh 1 Mesh 2 Mesh

Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 50Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 20 days
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Firm Structure Material SS304 Or SS316
Color Bright Silver Type Welded
Hole Shape Square Hole Or Slot Hole Mesh Counts 1mesh, 2mesh, 3mesh, 4mesh
Width Up To 2m Clear Opening 4", 3", 2", 1-3/4", 1-1/2", 1-1/4", 1", 3/4", 1/2", 1/4"
Mesh Size(Center To Center) 4", 3", 2", 1-3/4", 1-1/2", 1-1/4", 1", 3/4", 1/2", 1/4" Application Fencing
High Light

TENGLU SS304 SS Welded Wire Mesh

,

TENGLU SS316L SS Welded Wire Mesh

,

TENGLU SS316L welded steel fence panels

Leave a Message
Product Description

Stainless Steel 304 And 316 In Panels Or Rolls SS Welded Wire Mesh



Brief Introduction



Stainless Steel Welded Wire Mesh
Welded wire mesh is constructed with two orthogonal wires that are joined together at their intersections using a resistance welding process to form a grid. The line wires of the grid are guided through the welder using a pattern board. The machine drops cross wires into place and fuses them together to create the two distinctive planes that form welded wire mesh. The hole shape of welded wire mesh is square or rectangle.



Stainless steel welded wire mesh is an extremely popular and versatile item that use for many different applications by many different customers all over the world. We specialize in producing high quality stainless steel welded wire mesh, both 304 stainless steel and 316 stainless steel are very common in our factory. Stainless steel welded wire mesh is corrosion resistant, uniform in appearance and available from stock or through custom manufacturing.



We generally offer stainless steel welded wire mesh in rolls or panels. As the strong and consistent features of the welds, it is an ideal option for general industrial use, it can be cut down to smaller sizes, such as rectangles, squares, discs or other required shapes.



Aside from stainless steel’s corrosion resistance and clean look, another benefit of selecting a stainless steel welded wire mesh is that because the wires are physically welded at each intersection, the mesh will remain intact and rigid. Strong and consistent welds make stainless steel welded wire mesh an ideal option for general industrial use because welded mesh can be cut down to smaller sizes without fraying, like rectangles, squares or discs.



Common Material:



SS304, SS304L, SS316, SS316L. Stainless steel in other alloy are availble.



Features:



Easy to clean;

Easy to install;

Strong structure;

Beautiful outlook;

Corrosion resistance;

Acid resistance;

Alkali resistance;

Wear resistance;

Flat surface;

Solid structure, strong integrity, even if the cut or in part under pressure not loose or slack.



Applicatioins:



Infill panel & railing systems;
Industrial fan & machine guards;
Security enclosures;
Animal retention (cages);
Small critter control;
Decorative signage;
Room dividers;
Wall cladding;
Ceiling panels;
Air vents & soffit screens;
Basket fabrication;
Food applications;
Racking & storage;
Aviary & bird screen;
Industrial separation.



Specifications:



1) Clear Opening. Sample: 1" Opening = a 1" opening, measured from inside wire edge to inside wire edge.

Stainless Steel Welded Wire Mesh Specifications
Clear Opening Wire Diameter Opening
4″Opening 0.250″ 4.000″
3″Opening 0.250″ 3.000″
3″Opening 0.187″ 3.000″



2) Mesh Counts(Meshes/Inch). Sample: 2 Mesh = a total of 2 equal openings within a 1" measurement, from center to center of wire.

Stainless Steel Welded Wire Mesh Specifications
Mesh Counts Wire Diameter Opening
2 0.063″ 0.437″
2 0.047″ 0.453″
2 0.041″ 0.459″
2 0.035″ 0.465″
3 0.047″ 0.286″
3 0.038″ 0.295″
4 0.047″ 0.203″
4 0.032″ 0.218″
4 0.028″ 0.222″



3) Mesh Size(Center to Center). 1" Mesh = a 1" measurement from center to center of wire.

Stainless Steel Welded Wire Mesh Specifications
Mesh(Center to Center) Wire Diameter Opening
2″×2″ 0.250″ 1.750″
0.192″ 1.808″
0.187″ 1.813″
0.162″ 1.838″
0.148″ 1.852″
0.135″ 1.865″
0.120″ 1.880″
0.105″ 1.895″
0.080″ 1.920″
0.063″ 1.937″
2″×4″ 0.105″ 1.895″×3.895″
1″×2″ 0.080″ 0.920″×1.920″
1″×1-1/2″ 0.612″ 1.338″
0.135″ 1.365″
0.120″ 1.380″
1″×1″ 0.148″ 0.852″
0.135″ 0.865″
0.120″ 0.880″
0.105″ 0.895″
0.080″ 0.920″
0.063″ 0.937″
0.047″ 0.953″
0.022″ 0.978″

Other "Mesh Size", "Mesh Counts", "Wire Diameter", "Opening" as your requests.



Stainless Steel 304 And 316 SS Welded Wire Mesh 1 Mesh 2 Mesh 0



Welded Wire Mesh in Rolls/Panels, SS304, SS316, Stainless Steel in Other Alloy



Packing:



in waterproof paper in rolls. Custom packing available at request.
