Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant

  • Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant
  • Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant
  • Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 1 roll
Price Negotiable according to quantity of order
Packaging Details 1. inside use carton pipe for support+wire mesh layer+water proof paper 2. outside use plastic wooden bags+wooden case/carton pipes/wooden pallets. 3. also we can as per your requirements.
Supply Ability 3000 rolls per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Dutch Wire Mesh Material Stainless Steel 304 316
Cert ISO9001 Max Counts 325 X 2300
Width 0.1 To 2.0m Length 30m Or Customized
Color Silver Hole Shape Square Or Customized
Wire Diameter 0.0183mm-2.03mm, 1-635mesh Application Filtering
Highlight

dutch weave wire mesh

,

dutch weave screen mesh
Leave a Message
Product Description

Main FeaturesStainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant



Stainless steel wire raw material is selected for their wear-resisting, heat-resisting, acid-resisting and corrosion resisting characteristics. Many different grades of stainless are used in wire cloth. T304 is the most common



Wire Materials:



SUS302, 304, 316, 304L, 316L.



Characteristics:



Square aperture, less rigid than plain weave, especially suitable for deforming, strong

wire cloth due to ratio of wire diameter and aperture, it is mostly used for filtration less than 63 μm .


Weaving Patterns:



Plain weave, twill weave, dutch weave.



Packing:



stainless steel mesh made in small rolls,outside wooden cases.



Main Features:


Corrosion resistance.

Anti-acid and alkali.
Anti-high temperature.
Good filter performance.
Long using life


Applications:


Mining, chemical, food, petroleum, medicine, etc., mainly used in gas, liquid filtration and other media separation
1.Petroleum industry
2.Pharmaceutical industry
3.Food industry
4.Water treatment industry
5.Chemical industry
6.Paper making industry
7.Plastic recycling industry



Details sheet:



Sheet2: Specifications of Twill Dutch Weave Wire Mesh

Mesh/Inch

Warp×Weft

Wire Diameter

Warp×Weft

(mm)

 Aperture Size
μm

Weight

kg/㎡

Thickness

(mm)
20×270 0.25×0.2 119 3.14 0.65
20×200 0.355×0.28 118 4.58 0.915
24×300 0.28×0.18 110 3.01 0.64
20×150 0.45×0.355 101 6.02 1.16
30×340 0.28×0.16 89 2.84 0.60
30×270 0.28×0.20 77 3.41 0.68
40×540 0.18×0.10 70 1.73 0.38
40×430 0.18×0.125 63 2.09 0.43
50×600 0.125×0.09 51 1.47 0.305
50×500 0.14×0.11 47 1.83 0.364
65×600 0.14×0.09 36 1.59 0.32
70×600 0.14×0.09 31 1.61
78×760 0.112×0.071 1.25 0.254
78×680 0.112×0.08 29 1.37 0.272
80×680 0.112×0.08 28 1.38
90×850 0.10×0.063 26 1.12 0.226
90×760 0.10×0.071 24 1.23 0.242
100×850 0.10×0.063 22 1.14 0.226
130×1500 0.063×0.036 21 0.64 0.135
100×760 0.10×0.071 20 1.25 0.242
130×1200 0.071×0.045 18 0.80 0.161
130×1100 0.071×0.05 17 0.87 0.171
150×1400 0.063×0.04 15 0.71 0.143
160×1500 0.063×0.036 0.67 0.135
165×1500 0.063×0.036 14
174×1700 0.063×0.032 13 0.62 0.127
165×1400 0.063×0.04 0.73 0.143
174×1400 0.063×0.04 11 0.74
203×1600 0.05×0.032 10 0.58 0.114
216×1800 0.045×0.03 0.53 0.105
203×1500 0.056×0.036 9 0.67 0.128
250×1900 0.04×0.028 8 0.51 0.096
250×1600 0.05×0.032 0.63 0.114
285×2100 0.036×0.025 7 0.44 0.086
300×2100 0.036×0.025 6
317×2100 0.036×0.025 5
325×2300 0.036×0.024 4
363×2300 0.032×0.022 0.40 0.076





Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant 0Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant 1







Delivery Time
We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material. We'll check with our production department for the non-stock items to offer you the exact delivery time and producing schedule.

Mutual Benefit
If the products of our distributors are unmarketable due to the influence by market factors,we will seek customers in the same market or near market who are in need of the products to help the distributors to handle unsalable products.



Our other products



Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant 2



Stainless Steel Dutch Weave Wire Cloth 100 Micron Filter Mesh With Wear Resistant 3



Anping Qianpu Wire Mesh Products Co., Ltd.is a manufacture and exporter of stainless steel wire mesh product.

We are located in wire mesh industrial base Anping city,Hebei province in China.

Our product range is as below,

Stainless steel woven wire mesh

Welded wire mesh

Crimped wire mesh

Hexagonal wire mesh

Knitted wire mesh

Wire mesh filter

Window screen



It have been 15 years that we manufacture and export wire mesh product,our professional responsible attitude and our strictly management technique ensure us standing in the leading position of wire mesh industry.We welcome your enquiry.



In order to make an offer,please provide us below wire mesh specification information.

Material

Wire diameter

Mesh size

Wire mesh length

Wire mesh width

If it is possible,please also provide us weight per roll that you required.
