10 Mesh SS304 Stainless Security Mesh Square Hole 12 Mesh 11 Mesh

  • 10 Mesh SS304 Stainless Security Mesh Square Hole 12 Mesh 11 Mesh
  • 10 Mesh SS304 Stainless Security Mesh Square Hole 12 Mesh 11 Mesh
  • 10 Mesh SS304 Stainless Security Mesh Square Hole 12 Mesh 11 Mesh
Place of Origin Anping of China
Brand Name QIANPU
Certification ISO
Minimum Order Quantity 10Rolls
Price Negotiable
Packaging Details Inside with a paper tube, outside with plastic film or waterproof paper, then in wooden case or pallets.
Delivery Time 2 weeks
Payment Terms T/T, Western Union, L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Security Screen Mesh Material SS304 SS316
Standard AISI, DIN, SUS, Etc Hole Shape Square Hole
Mesh Counts 10, 11, 12, Etc Surface Painted Or Powder Coated
Width 0.5m O 1.5m Length 1m To 2.4m
Property High Durable Application Screen For Window And Doors
Highlight

10 Mesh stainless security mesh

,

SS304 stainless security mesh

,

11 Mesh 304 stainless steel wire mesh
Leave a Message
Product Description

Chemical compositionHigh Durable Stainless Steel, Security Screen for Window and Doors

Security Screen for Window and Doors Introduction:



SS Windon Screen Mesh, Anti-Theft Stainless Steel Security Window Screen, Insect window screen, Fire proof insect window screen.Invisible metal window screen. anti-insect window screen, anti-fly mesh, anti-mosquito screen.Anti-Theft Stainless Steel Security Window Screen,Knife Proof stainless steel window screen.



We produces and exports different sizes of stainless steel security screen to the world, especially to Australia, America and Europe.

Stainless steel security screen can be used for window and door.



Chemical composition:



Chemical composition of stainless steel wire:
Grade Chemical Composition(%)
  C Si Mn P S Ni Cr Mo
304 =0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304H >0.08 =1.00 =2.00 =0.045 =0.030 8.00~10.50 18.00~20.00 -
304L =0.030 =1.00 =2.00 =0.045 =0.030 9.00~13.50 18.00~20.00 -
316 =0.045 =1.00 =2.00 =0.045 =0.030 10.00~14.00 10.00~18.00 2.00~3.00
316L =0.030 =1.00 =2.00 =0.045 =0.030 12.00~15.00 16.00~18.00 2.00~3.00
430 =0.12 =0.75 =1.00 =0.040 =0.030 =0.60 16.00~18.00 -
430A =0.06 =0.50 =0.50 =0.030 =0.50 =0.25 14.00~17.00 -




Sepecifications:



Material Mesh per inch

Wire Dia

Mm / inch

 Open (mm)

Open Area

%

 Market Area
SS 316 or 304 10 x 10 0.9mm /0.035" 1.64 41.7

Australia

America

Europe
SS 316 or 304 10 x 10 1.2mm /0.028" 1.34 27.8
SS 316 or 304 10 x 10 0.8mm / 0.032" 1.74 46.9
SS 316 or 304 10 x 10 1.15mm / 0.045" 1.39 29.9
SS 316 or304 11 x 11 0.8mm /0.032" 1.5 42.5
SS 316 or 304 11 x 11 0.7mm / 0.027" 1.6 48.3
SS 316 or 304 12 x 12 0.7mm / 0.027" 1.42 44.8
SS 316 or 304 12 x 12 0.58mm / 0.023" 1.54 52.8
Special mesh can be made according to customers requirement



Stainless Steel 316 Security Screen, 1.5mm Aperture, 0.8mm Thickness



Stainless Steel Security Window Screen:


Material type: Stainless steel 304,304l,316,316l,
Weave type: plain weave style
Common specification: 11 mesh * 0.8mm wire, 11 mesh* 0.9mm wire,10 mesh * 0.9mm wire, 12mesh* 0.7mm wire,14 mesh* 0.6mm wire, 14 mesh * 0.7mm wire
Standard size: 750mm×2000mm 900mm×2000mm 1200mm×2000mm 750mm×2400mm 900mm×2400mm 1200mm×2400mm,1300mmx2600mm, 1500mmx2400mm.
Color: black,white, gray, dark gray, etc.(Note: If color painted, the max width is 1.5m)



Features:



1. Against theft, bulletproof, super resistance to impact, insect and so on.
2. mooth surface, mesh standard, latitude and longitude curve is consistent, its remarkable characteristic is BanShi hard like iron, is against theft, bulletproof, home of choice for workplace ety protection.
3. Bulletproof Mesh Screen Features :
--very high bounce impact force,the most feature and application.
-- as window screen ,it has good view inside room,but hazy for person outside room
--easy to clean
--power coated



Packing:



10 Mesh SS304 Stainless Security Mesh Square Hole 12 Mesh 11 Mesh 1
